ASUS Pro WS TRX50-SAGE WIFI DDR5 E-ATX (CEB) Motherboard
Web ID: 38719
CPU Socket: AMD sTR5 || For AMD Threadripper Processors
Form Factor: E-ATX
Chipset: AMD TRX50
Memory Type: RDIMM DDR5
WiFi Standard: Wireless-BE + Bluetooth
Storage Interface: 3 x M.2 PCIe || 4 x SATA 6Gb/s
LAN Speed: 1 x 2.5 Gigabit || 1 x 10 Gigabit
Audio: 5.1 Channel
USB: 6 x USB 3.2 Type-A || 1 x USB 3.2 Type-C || 2 x USB 2.0
Internal USB Ports: 2 x USB 3.1 Header || 1 x USB 3.2 Type C Header || 2 x USB 2.0 Header
Manufacturer Warranty: 3 Year
Manufacturer PN: PRO WS TRX50-SAGE WIFI
GTIN: 197105337756
Manufacturer Website
$1699
| Model | Pro WS TRX50-SAGE WIFI |
|---|---|
| CPU | AMD Socket sTR5 for Ryzen™ Threadripper™ PRO 9000 & 7000 WX-Series and Ryzen™ Threadripper™ 9000 & 7000 Series Processors Refer to www.asus.com for CPU support list. System boot may take longer with Threadripper™ 9000 series CPUs due to memory calibration. |
| Chipset | AMD TRX50 Chipset |
| Memory | 4 x DIMM slots, DDR5, ECC Registered Memory 4 Channel Memory Architecture See CPU/Memory Support. |
| Expansion Slots | 2 x PCIe 5.0 x16 slots 1 x PCIe 5.0 x16 slot (x8 mode) 1 x PCIe 4.0 x16 slot 1 x PCIe 4.0 x16 slot (x4 mode) |
| Storage | 3 x M.2 slots 4 x SATA 6Gb/s ports 1 x SlimSAS port (PCIe 4.0 x4 NVMe) Supports AMD RAIDXpert2 RAID 0/1/5/10. |
| Ethernet | 1 x Marvell® AQtion 10Gb Ethernet 1 x Intel® I226-LM 2.5Gb Ethernet |
| Wireless & Bluetooth | Wi-Fi 7 (2x2, 802.11be) Supports 2.4/5/6GHz bands Bluetooth® v5.4 Wi-Fi 7 requires Windows 11 SV3 or later for full functionality. |
| USB (Rear) | 1 x USB 20Gbps (Type-C®) 6 x USB 10Gbps (Type-A) 2 x USB 2.0 (Type-A) |
| USB (Front) | 1 x USB 20Gbps (Type-C®, up to 27W PD/QC4+) 1 x USB 5Gbps header (adds 2 ports) 2 x USB 2.0 headers (adds 4 ports) |
| Audio | Realtek ALC1220P HD Audio CODEC Supports up to 32-Bit/192 kHz playback Rear optical S/PDIF out port Supports 5.1 Surround Sound with HD audio chassis. |
| Back Panel I/O | 1 x USB 20Gbps (Type-C®) 6 x USB 10Gbps (Type-A) 2 x USB 2.0 (Type-A) Wi-Fi module Marvell® 10Gb Ethernet Intel® 2.5Gb Ethernet 2 x Audio jacks Optical S/PDIF out BIOS FlashBack™, Clear CMOS |
| Internal I/O | CPU Fan, CPU OPT, W_PUMP+, 4 x Chassis Fan, VRM Fan Power: 2 x 24-pin, 2 x 8-pin +12V, PCIe connectors Misc headers: BMC, USB4, TPM, FlexKey, LN2 jumper, Start button |
| Special Features | ASUS Q-Design (Q-Code, Q-Latch, Q-LED, etc.) ASUS Thermal Solution (M.2 heatsinks, VRM fans) ASUS EZ DIY (BIOS FlashBack™, Clear CMOS, SafeSlot) |
| Software | Armoury Crate (Fan Xpert 4) ASUS CPU-Z Adobe Creative Cloud (Trial) Norton 360 Deluxe (60-day trial) WinRAR (40-day trial) |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE (UEFI mode) |
| Accessories | 2 x SATA cables CPU 8-pin to PCIe adapter Thermistor cable pack ASUS WiFi Q-Antenna M.2 Q-Latch package |
| Operating System | Windows® 11 |
| Form Factor | CEB, 12" x 11" (30.5 cm x 28.3 cm) |
