Product Specifications

• Image Sensor

  1/2.8″ Progressive CMOS

• Dimensions

  Ø: 146mm / 5.75in, H: 104.3mm / 4.11in with mount plate
  Ø: 146mm / 5.75in, H: 99.8mm / 3.93in without mount plate

• Image Resolution*

  5MP / 2688 x 1944

• IR Range

  15m / 50ft

• Onboard Storage

  From 256GB to 2TB

• Lens Type

  Fixed

• Day/Night

  IR-cut filter for day & night function

• Focus

  Fixed

• Focal Length

  2.8mm

• Aperture

  F1.6

• Connectivity

  RJ-45 cable connector for Network/PoE connection

• Field of View (after LDC**)

  Horizontal: 97° (78°)
  Vertical: 71° (63°)
  Diagonal: 128° (91°)

• Power Input

  IEEE 802.3af PoE

• Power Consumption

  8.59W

• Iris

  Fixed

• Audio

  Yes

• Weight

  Camera: 593g / 20.92oz
  Mountplate: 143g / 5.04oz

• Certifications

  UL, FCC, CB, CE, BIS, NOM, KCC

• Operating Temperature

  -10°C - 50°C / 14°F - 122°F

• Humidity

  90%

• Included Accessories

  Setup guide, T10 security Torx screwdriver, screw pack, mounting template

• LED Indicator

  System power and status indicator

• RTSP

  RTSP 1.0
  RFC 2326
  Max Concurrent Streams: 2
  Audio Support: Yes

All of our cameras record footage in adaptive quality. Learn More

Lens Distortion Correction (LDC) crops the sensor field of view to deliver a rectified, undistorted output image.
