| CPU | |
|---|---|
| CPU | LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors |
| L3 Cache | L3 cache varies with CPU |
| CPU Support Note | (Please refer to "CPU Support List" for more information.) |
| Chipset | |
| Chipset | Intel® B760 Express Chipset |
| Memory | |
| Memory Support | Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules |
| DIMM Slots | 2 x DDR4 DIMM sockets supporting up to 64GB (32 GB single DIMM capacity) of system memory |
| Memory Architecture | Dual channel memory architecture |
| ECC Support | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) |
| Non-ECC Support | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
| XMP Support | Support for Extreme Memory Profile (XMP) memory modules |
| Memory Support Note | (Please refer "Memory Support List" for more information.) |
| Onboard Graphics | |
| Graphics Processor | Integrated Graphics Processor-Intel® HD Graphics support |
| D-Sub Port | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz |
| HDMI Port | 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
| HDMI Support | * Support for HDMI 2.1 version and HDCP 2.3. |
| HDMI Note | ** Support native HDMI 2.1 TMDS compatible ports. |
| Graphics Note | (Graphics specifications may vary depending on CPU support.) |
| Audio | |
| Audio Codec | Realtek® Audio CODEC |
| Audio Standard | High Definition Audio |
| Channels | 2/4/5.1/7.1-channel |
| Audio Configuration Note | * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
| S/PDIF Support | Support for S/PDIF Out |
| LAN | |
| LAN | Realtek® GbE LAN chip (1 Gbps/100 Mbps) |
| Expansion Slots | |
| CPU PCIe Slot | 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 |
| PCIEX16 Note | * The PCIEX16 slot can only support a graphics card or an NVMe SSD. |
| Chipset PCIe Slot | 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
| Storage Interface | |
| CPU M.2 | 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) |
| Chipset M.2 | 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB) |
| SATA Ports | 4 x SATA 6Gb/s connectors |
| RAID Support | RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
| USB | |
| USB 3.2 Gen 1 | 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header) |
| USB 2.0/1.1 | 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) |
| Internal I/O Connectors | |
| ATX Main Power Connector | 1 x 24-pin ATX main power connector |
| ATX 12V Power Connector | 1 x 8-pin ATX 12V power connector |
| CPU Fan Header | 1 x CPU fan header |
| System Fan Headers | 2 x system fan headers |
| RGB LED Header | 1 x RGB LED strip header |
| M.2 Socket 3 Connectors | 2 x M.2 Socket 3 connectors |
| SATA Connectors | 4 x SATA 6Gb/s connectors |
| Front Panel Header | 1 x front panel header |
| Front Panel Audio Header | 1 x front panel audio header |
| S/PDIF Out Header | 1 x S/PDIF Out header |
| USB 3.2 Gen 1 Header | 1 x USB 3.2 Gen 1 header |
| USB 2.0/1.1 Headers | 2 x USB 2.0/1.1 headers |
| TPM Header | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
| Serial Port Header | 1 x serial port header |
| Clear CMOS Jumper | 1 x Clear CMOS jumper |
| Back Panel Connectors | |
| USB 2.0/1.1 Ports | 2 x USB 2.0/1.1 ports |
| D-Sub Port | 1 x D-Sub port |
| HDMI Port | 1 x HDMI port |
| USB 3.2 Gen 1 Ports | 4 x USB 3.2 Gen 1 ports |
| RJ-45 Port | 1 x RJ-45 port |
| Audio Jacks | 3 x audio jacks |
| I/O Controller | |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | |
| Voltage Detection | Supported |
| Temperature Detection | Supported |
| Fan Speed Detection | Supported |
| Water Cooling Flow Rate Detection | Supported |
| Fan Fail Warning | Supported |
| Fan Speed Control | Supported |
| Fan Speed Control Note | * Whether the fan speed control function is supported will depend on the cooler you install. |
| BIOS | |
| Flash | 1 x 128 Mbit flash |
| BIOS Type | Use of licensed AMI UEFI BIOS |
| Standards | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | |
| GIGABYTE Control Center (GCC) | Support for GIGABYTE Control Center (GCC) |
| GCC Note | * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. |
| Q-Flash | Support for Q-Flash |
| Bundled Software | |
| Software | Norton® Internet Security (OEM version) |
| LAN Software | LAN bandwidth management software |
| Operating System | |
| Windows 11 | Support for Windows 11 64-bit |
| Windows 10 | Support for Windows 10 64-bit |
| Form Factor | |
| Form Factor | Micro ATX Form Factor; 23.0cm x 21.5cm |
