SilverStone RM41-506 Black 4U Rackmount Case No PSU
Web ID: 32950
Supports up to SSI-CEB motherboard
Supports Standard profile PCI / PCIe x 7 slots
Six 5.25" drive bays for flexible 5.25" device installation
5Gbps Super Speed USB 3.1 Gen 1 interface, backward compatible with USB 2.0 / 1.1
Mounting holes ready for quick rail slide installation (rail slide sold separately)
Manufacturer Warranty: 1 Year
Manufacturer PN: SST-RM41-506
GTIN: 844761019228
Manufacturer Website
$289
SPECIFICATIONS
Model No. | SST-RM41-506 | |
Chassis form factor | 4U | |
Material | SGCC | |
Motherboard | CEB (12" x 10.5"), ATX (12" x 9.6"), Micro ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7") | |
Drive Bay | External | 5.25" drive bay x 6 |
Internal | 4 x 3.5" 2 x 2.5” (up to 15mm) 1 x 2.5” (up to 15mm) or slim optical (12.7mm) |
|
Cooling System | Front | 80 x 25mm fan x 1(fan not included) |
Rear | 80 x 25mm fan x 2 | |
Power Supply | PS2 / ATX / Mini Redundant (supports up to 160mm) | |
Expansion card | Length w/ 5.25” drive cage: 278mm Length w/o 5.25” drive cage: 426mm |
|
Limitation of CPU cooler | 148mm | |
Expansion Slot | Standard profile PCI / PCIe x 7 | |
Front I/O Port | USB 3.1 Gen1 Type-A x 2 | |
Front buttons | Power On / Off, system reset | |
Indicators | Power status x 1, HDD activity x 1, LAN activity x 2 | |
Main metal thickness | 1.2mm | |
Net Weight | 9.7 kg | |
Dimension | 430mm (W) x 176mm (H) x 446mm (D) 16.93" (W) x 6.93" (H) x 17.56" (D) |
* The RM41-506 has two rows of mounting holes for sliding rails. If you wish to align RM41-506 in one whole U position as opposed to leaving half U height top and bottom, please secure rails to the bottom row of mounting holes. |
