Zotac GeForce RTX 5060 Twin Edge OC 8GB GDDR7 Graphics Card Black, Limit 1 per customer
Web ID: 48268
Chipset Manufacturer: NVIDIA Chipset
NVIDIA Series: NVIDIA RTX 5060
VRAM Size: 8GB VRAM
VRAM Type: GDDR7
VRAM Speed: 28Gbps
Display Output: HDMI Out || DisplayPort Out
Max. Displays: 4 Displays
PCIe Size: PCIe x16
GPU Technology: DLSS 4
Minimum PSU: 550 Watt
GPU Length: 230mm
Manufacturer Warranty: 3 Year
Manufacturer PN: ZT-B50600H-10M
Manufacturer Website
$559
| GPU | NVIDIA GeForce RTX 5060 GPU |
| CUDA Cores | 3840 |
| Video Memory | 8GB GDDR7 |
| Memory Bus | 128-bit |
| Engine Clock | 2527 MHz |
| Memory Clock | 28 Gbps |
| AI TOPS | 614 |
| PCI Express | PCI Express 5.0 x8 |
| Display Outputs | 3 x DisplayPort 2.1b with UHBR20 (up to 4K 480Hz or 8K 165Hz with DSC) 1 x HDMI® Connector (Supports 4K 480Hz HDR or 8K 120Hz HDR with DSC, and Gaming VRR as specified in the HDMI 2.1b Specification) |
| HDCP Support | 2.3 |
| Multi Display Capability | Quad Display |
| Recommended Power Supply | 550W |
| Power Consumption | 145W |
| Power Input | 1 x 8-pin power input |
| DirectX | Microsoft DirectX® 12 Ultimate |
| OpenGL | 4.6 |
| Cooling | Air Cooled |
| Slot Size | 2 |
| SLI | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 November 2018 or later) |
| Card Length | 220.5mm x 120.25mm x 41.6mm / 8.7" x 4.7" x 1.6" |
| Accessories | User Manual |
