| Warranty Information | |
|---|---|
| Warranty | 1 Year |
| Hardware | |
| 4K Support | Yes |
| Bus Type | USB-C |
| Chipset ID | VL103-Q3+EM5200 |
| Displays Supported | 2 |
| Performance | |
| Maximum Digital Resolutions | USB-C DP1.4: Dual Monitor (SST): 4K@60Hz | Dual Monitor (MST): 4K@60Hz USB-C DP1.2: Dual Monitor (SST): 4K@60Hz | Dual Monitor (MST): 4K@30Hz MST mode only compatible with Windows OS. Only SST is supported on Mac OS. |
| Connector(s) | |
| Connector Type(s) | 1 – USB Type-C (24 pin) USB 3.0 Male |
| 2 – HDMI 2.0 (19 pin) Female | |
| Special Notes / Requirements | |
| Note | Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure that your host USB-C port supports DP alt mode. |
| A 4K-capable display is required to achieve 3840 x 2160p resolution (4K is also known as 4K x 2K) | |
| OS Suport | Windows7/8/10, Google Chrome OS, Mac OS X Yosemite, Mac OS X El Capitan,Mac OS sierra or above. |
| Power | |
| Power Source | USB-Powered |
| Environmental | |
| Humidity | 0~90% RH (Non-condensing) |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | 5°C to 45°C |
| Physical Characteristics | |
| Color | Black |
| Enclosure Type | Aluminium |
| What’s in the Box | |
| Included in Package | 1 – VL-UC2H 1- User Manual |
