| CAMERA | |
|---|---|
| Image Sensor | 1/2.65” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Aperture | F1.6 |
| Lens | 4 mm, Fixed Focal Lens, M12 |
| FOV | Horizontal FOV: 92°, Vertical FOV: 48°, Diagonal FOV: 110° |
| Minimum Illumination | 0.005 Lux; 0 Lux with IR/White Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Auto |
| Integrated Infrared-White LED | • Quantity: 2 • IR Range: 98 ft (30 m) • White LED Range: 98 ft (30 m) • IR Wavelength: 850 nm |
| Illuminator On/Off Control | Auto/Always on/Always off |
| Max. Resolution | 2880 x 1620 (5MP) |
| Main Stream | • Frame Rate: 50Hz: 25fps (2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720) 60Hz: 30fps (2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720) |
| Sub-Stream | • Frame Rate: 50Hz: 25fps (848x480,704x576, 640x480, 640x360,352x288, 320x240) 60Hz: 30fps (848x480,704x576, 640x480, 640x360,352x288, 320x240) |
| Video Bit Rate | • Main Stream: 256 Kbps to 6144 Kbps • Sub-Stream: 64 Kbps to 512 Kbps |
| Video Compression | • Main Stream: H.265+/H.265/H.264+/H.264 • Sub-Stream: H.265/H.264 |
| Event | • Motion Detection (People Detection, Vehicle Detection, Pet Detection) • Intrusion Detection (People Detection, Vehicle Detection, Pet Detection) • Line-Crossing Detection (People Detection, Vehicle Detection, Pet Detection) • Video Tampering Detection |
| Recording Modes | N/A |
| Interface & Button | • Buit-in Microphone; Records Anything Going on within a 16.4ft (5m) Radius of the Camera • 1× RJ45 10/100Mbps Self-Adaptive Ethernet Port, PoE • 1× DC Port |
| Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Power Supply | DC • 12V DC ± 5%, Max. 7.4 W, 5.5 mm Coaxial Power Plug • Recommended Power Supply: T120100-2C1 (for EU Regions) PoE • PoE: 802.3af/at, Max. 8.7 W ErP Information • Power consumption in networked standby when all wired network ports are connected and all wireless network ports are activated: 2.2 W |
| Protection | • IP67 Weatherproof • IK08 Vandal Proof |
| Product Dimensions (L x W x H) | 4.4 × 4.4 × 3.4 in (112 × 112 × 87 mm) |
| Weight | Net Weight: 0.45 kg (0.99 lbs) |
| NVR | |
|---|---|
| IP Video Input | 16-Channel** |
| Managed Cameras | • 16 (HD) • 16 (2K/5MP) • 12 (4K/8MP) • 8 (12MP) • 6 (16MP) |
| HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz, 2560x1440/60Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Record Resolution | 16MP / 12MP / 8MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF/ QCIF |
| Synchronous Playback | 16-Channel |
| Decoding Capability | • 25fps: 10-ch @ 2MP • 30fps: 1-ch @ 16MP, 2-ch @ 8MP, 4-ch @ 5MP, 5-ch @ 4MP, 6-ch @ 3MP |
| Hard Disk | • 1× SATA Interface, Up to 16 TB Capacity • 1× 2TB HDD Preinstalled |
| PoE Budget | 115 W Available for All PoE+ Ports, 30 W Max per Port |
| External Interfaces | • 1× eSATA, Supports External Storage Devices up to 16TB • 1× HDMI Port • 1× VGA Port • 1× Front USB 2.0 Port, 1× Rear USB 3.0 Port • 1-ch RCA Audio Input (1.4 Vp-p, 10KΩ), 1-ch RCA Audio Output (2.8 Vp-p, 1KΩ) • 1× 10/100/1000 Mbps Self-Adaptive Ethernet Port • 1× DC Power Supply Port • 8× PoE+ Ports |
| Network Protocol | • UPnP (Plug and Play) • NTP (Network Timing) • SMTP • DNS • TCP/IP • UDP • ICMP • HTTP • HTTPS • DHCP • RTSP • SSL/TLS • RTP • IPv4 • ARP • LLDP • FTP • IPv6 • SNMP |
| Web Browser | • Chrome (57+) • Firefox (52+) • Edge (91+) |
| Max. User Access | 40 Users; Support up to 32 Simultaneous Video Streams |
| Power Supply | 53.5V DC/2.43 A |
| Working Temperature | • NVR: -10 °C to 55 °C (14 ? to 131 ?) • Power Adapter: 0 °C to 40 °C (32 ? to 104 ?) |
| Interoperability | ONVIF Profile G/S/T |
| Product Dimensions (L x W x H) | 10.2 × 9.1 × 1.8 in (260 × 230 × 45 mm) |
| Weight | Net Weight: 2.23 Kg (4.92 lbs) |
1 Year
Manufacturers Warranty
