LAN Speed: 1 Gigabit
Wireless Channel: Dual Band || 2.4GHz || 5GHz
Connection Type: Wireless
| HARDWARE FEATURES | |
|---|---|
| Interface | 1× Gigabit Ethernet Port |
| Button | Reset |
| DIP Switch | Pairing Code Switch |
| Power Supply | • 12V DC/1A • 802.3af PoE • 24V Passive PoE (Passive PoE Adapter Included - For Dry Indoor Use Only) |
| Max. Power Consumption | DC: 9W PoE: 10.5W |
| Dimensions ( W x D x H ) | 14.1 × 4.9 × 2.8 in (358.5 × 124.6 × 70.5 mm) |
| Antenna | • 2.4 GHz: 1 × 4 dBi (peak gain), internal omnidirectional antennas • 5 GHz: 2 × 16 dBi (peak gain), internal directional antennas • Beamwidth: Horizontal 120°, Vertical 13° |
| Weatherproof Enclosure | IP66 |
| Mounting | Pole and wall mounting (Kits included) |
| Management Features | |
|---|---|
| Omada App | Yes |
| Restore & Backup | Yes |
| Firmware update via Web | Yes |
| NTP | Yes |
| Centralized Management | • Omada Central (Cloud-Based) • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Require the use of an Omada Controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| SNMP | Yes |
| SSH | Yes |
| Web-based Management | Yes |
| Zero-Touch Provisioning | Yes |
| WIRELESS FEATURES | |
|---|---|
| PtP | Yes |
| PtMP | 32 Maximum |
| Transmission Distance | 3.1 mi (5,000 m) |
| Wireless Standards | IEEE 802.11a/b/g/n/ac |
| Frequency | • 2.4 GHz (Device Management Only) • 5 GHz |
| Signal Rate | 5 GHz: Up to 867 Mbps |
| Wireless Functions | • MU-MIMO: 5G 2x2 MU-MIMO DL • Wireless Statistics • Reboot Schedule • RADIUS Accounting • Static IP/Dynamic IP • Rate Limit • Enable/Disable Wireless Radio • Enable/Disable SSID Broadcast |
| Wireless Security | • VLAN • Rogue AP Detection • WPA/WPA2 |
| Transmission Power | • CE: 6-23 dBm (5 GHz, U-NII-1 & U-NII-2A, EIRP) 6-30 dBm (5 GHz, U-NII-2C, EIRP) • FCC: 4-23 dBm (5 GHz, U-NII-1) 4-25 dBm (5 GHz, U-NII-3) |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Content | • Sector Bridge 5 • Installation Guide • Mounting Kit • Passive PoE Adapter • Power Cord |
| Lightning Protection | • Air discharge: ±8kV • Contact discharge: ±4kV • Common mode 10/700: ±6kV |
| Environment | • Operating Temperature: -40 °C–70 °C (-40 °F–158 °F); • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F); • Operating Humidity: 10%–90% non-condensing; • Storage Humidity: 5%–90% non-condensing |
