$649
Click & Collect
In stock at Mt Gravatt
Delivery
Available for Fast Dispatch
Buy Now, Pay Later. T&Cs Apply
| Overview | |
|---|---|
| Built-In Omada Applications | • Network Application • Guard Application |
| Managed Devices | • Recommended Omada Network Devices: 30§ • Recommended Cameras: 16 HD / 14 2K / 12 4K (24 4K with an NVR)§ • Recommended NVRs: 1 • Omada SightCast: Supported |
| Client Capacity | Recommended for up to 300 Connected Clients§ |
| Interface | • 1× 2.5G RJ45 WAN Port • 8× 2.5G RJ45 LAN/WAN Ports • 8× PoE+ Ports with 180W Total Budget • Up to 8 Simultaneous WAN Ports |
| IPS Throughput | 2,364 Mbps |
| Site-to-Site VPN Throughput | 1,332 Mbps |
| Management | • Cloud Access • Account & Role • Local Management • Omada App • Multi-Site Management |
| Mounting | • Desktop • Wall-Mount (Magnetic-Mount Plate Sold Separately) • Rack-Mount (Rackmount Kit Sold Separately) |
| Dimensions | 8.9 × 5.3 × 1.24 in (226 × 135 × 31.5 mm) |
| SECURITY | |
|---|---|
| IDS/IPS | √ |
| DPI | √ |
| Application-Based ACL | √ |
| Content Filtering | √ |
| Ad Blocker | √ |
| Safe Search | √ |
| DNS Security | √ |
| Firewall | √ |
| Attack Defense | √ |
| ARP Inspection | √ |
| VPN & SD-WAN | |
|---|---|
| Omada LightLink VPN | √ |
| Site-to-Site VPN | WireGuard VPN / IPsec VPN |
| VPN Server | WireGuard VPN / OpenVPN / IPsec VPN / SSL VPN / L2TP VPN / PPTP VPN |
| VPN Client | WireGuard VPN / OpenVPN / L2TP VPN / PPTP VPN |
| SD-WAN | Full Mesh Mode |
| VPN Throughput | • Omada LightLink VPN: 1,017 Mbps • IPsec VPN: 1,332 Mbps • WireGuard VPN: 1,044 Mbps • OpenVPN: 393 Mbps • L2TP VPN: 1,109 Mbps • PPTP VPN: 404 Mbps • SSL VPN: 371 Mbps |
| Network Management | |
|---|---|
| Dashboard-Overview/Wi-Fi/Clients/Traffic | √ |
| Dashboard-Network Topology | √ |
| Health Monitoring | √ |
| Device Management | • Automatic Device Discovery • Batch Firmware Upgrade |
| Switch Ports | √ |
| Client Management | √ |
| Reports | √ |
| Logs | Alerts / Events / Audit Logs |
| Maintenance Tools | Ping Test / Packet Capture / Terminal / Cable Test / Interference Detection / Remote Access |
| IntelliRecover | √ |
| SNMP | v1/v2c/v3 |
| Bonjour/mDNS | √ |
| Dynamic DNS | Dyndns / No-IP / Peanuthull / Comexe / TP-Link DDNS / DDNS Customization |
| Multi-WAN Failover & Load Balancing | √ |
| IPv6 | Static IP / SLAAC / DHCPv6 / PPPoE / 6to4 Tunnel / Pass-Through / Non-Address Mode |
| VLAN Segmentation | √ |
| SSID | √ |
| PPSK | √ |
| WLAN Optimization | √ |
| QoS | √ |
| Portal | √ |
| Bluetooth | √ |
| NAT | √ |
| SURVEILLANCE MANAGEMENT | |
|---|---|
| Videos | • Live View • Playback |
| Device Management | √ |
| Events | √ |
| Smart Search | √ |
| Case Center | √ |
| Recording | √ |
| Logs | Alerts / System Events / Audit Logs |
| Storage Management | √ |
| Smart Analytics | √ |
| Archiving Management | √ |
| HARDWARE | |
|---|---|
| SSD Tray | 1× NVMe SSD Tray (Up to 2 TB Video Storage) |
| Touchscreen | 3.69-inch Color LCM Touchscreen |
| Button | Reset Button |
| Memory | 4 GB DDR4 |
| Power Supply | 100-240V~ 50/60Hz 54V/4.16A |
| PoE Budget | 8× Ports PoE+ Output, 180W PoE Budget§ |
| Max Power Consumption | 225 W, with Power Adapter |
| Enclosure | Polycarbonate |
| LED | Link, PoE |
| Fan | Quantity: 1 Noise: • Max: 28.0 dBA@1m • Min: Fanless Mode |
| Net Weight | Without SSD: 1.83 lb (828 g) |
| Surge Protection | 6 kV Surge Protection |
| Onboarding | Bluetooth or Ethernet |
5 Year
Manufacturers Warranty
Need a hand with something tech related? Our team put the human lingo in technology. Simply give us a call and we’ll be more than happy to assist!
PN: UA-Intercom-Viewer
Original price was: $309.$274Current price is: $274.
$649
