$279
Click & Collect
Out of stock
Delivery
Out of stock
Buy Now, Pay Later. T&Cs Apply
LAN Speed: 1 Gigabit
Wireless Channel: 5GHz Wireless
Connection Type: Wireless
| HARDWARE FEATURES | |
|---|---|
| Interface | 3× Gigabit Ethernet Ports (2 Support PoE Out) |
| Button | Reset |
| DIP Switch | • Role Switch • Pairing Code Switch |
| Power Supply | • 12V DC • 802.3at/af PoE • 24V Passive PoE (54V Passive PoE Adapter Included - For Dry Indoor Use Only) |
| Max. Power Consumption | DC: 12W PoE: 26.06W with PoE out |
| Dimensions ( W x D x H ) | 8.4 × 2 × 4.7 in (214.2 × 50.8 × 119.8 mm) |
| Antenna | • 2.4 GHz: 1 × 1 dBi (peak gain), internal omnidirectional antennas • 5 GHz: 2 × 17 dBi (peak gain), internal directional antennas • Beamwidth: Horizontal 40°, Vertical 18° |
| Weatherproof Enclosure | IP66 |
| Mounting | Pole and wall mounting (Kits included) |
| Management Features | |
|---|---|
| Omada App | Yes |
| Restore & Backup | Yes |
| Firmware update via Web | Yes |
| NTP | Yes |
| Centralized Management | • Omada Central (Cloud-Based) • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Require the use of an Omada Controller. |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| SNMP | Yes |
| SSH | Yes |
| Web-based Management | Yes |
| Zero-Touch Provisioning | Yes |
| WIRELESS FEATURES | |
|---|---|
| PtP | Yes |
| PtMP | 8 Recommended, 32 Maximum |
| Transmission Distance | 5,000 m (3.1 mi) |
| Wireless Standards | IEEE 802.11 a/n/ac |
| Frequency | 5 GHz |
| Signal Rate | 5 GHz: Up to 867 Mbps |
| Wireless Functions | • MU-MIMO: 5G 2x2 MU-MIMO DL • Multiple SSIDs: 1 • Wireless Statistics • Reboot Schedule • RADIUS Accounting • Static IP/Dynamic IP • Rate Limit • Enable/Disable Wireless Radio • Enable/Disable SSID Broadcast |
| Wireless Security | • VLAN • Rogue AP Detection • Wireless Encryption |
| Transmission Power | • CE: <23dBm (5 GHz, band 1/2, EIRP) <30dBm (5 GHz band3, EIRP) • FCC: <23.5dBm (5 GHz band1) <25dBm (5 GHz band4) |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Content | • Flex Bridge 5 • Installation Guide • Mounting Kit • Passive PoE Adapter • Power Cord |
| Lightning Protection | • Air discharge: ±8kV • Contact discharge: ±4kV • Common mode 10/700: ±6kV |
| Environment | • Operating Temperature: -40 °C–70 °C (-40 °F–158 °F); • Storage Temperature: -40 °C–70 °C (-40 °F–158 °F); • Operating Humidity: 10%–90% non-condensing; • Storage Humidity: 5%–90% non-condensing |
| Weight | 0.59 kg (1.3 lbs) |
3 Year
Manufacturers Warranty
