Connection Type: Wired
LAN Speed: 1 Gigabit
| SECURITY | |
|---|---|
| Access Control | • Source/Destination IP Based ACL • Stateful ACL • IPv4/IPv6 ACL • National Based ACL • FQDN |
| DPI | • Deep Packet Inspection • Support 2466 type Applications |
| DNS Proxy | DNSSEC, DoH, DoT, and DNS Override |
| Filtering | • Web Group Filtering§ • URL Filtering# • Web Security§ |
| Attack Defense | • TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN |
| ARP Inspection | • Sending GARP Packets§ • ARP Scanning§ • IP-MAC Binding • ARP Detection |
| VPN | |
|---|---|
| GRE | √ (Only in Standalone Mode) |
| IPsec VPN | • 20 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256 Encryption Algorithm • IPsec Failover • IKE v1/v2 • MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS) |
| PPTP VPN | • PPTP VPN Server • PPTP VPN Client (10)*** • 16 Tunnels • PPTP with MPPE Encryption |
| L2TP VPN | • L2TP VPN Server • L2TP VPN Client (10)*** • 16 Tunnels • L2TP over IPSec |
| OpenVPN | • OpenVPN Server • OpenVPN Client (10)*** • 50 OpenVPN Tunnels • "Certificate + Account" Mode • Full Mode |
| WireGuard VPN | √ |
| SD-WAN | √ (Only in Controller Mode) |
| HARDWARE FEATURES | |
|---|---|
| DSL Standards | • VDSL2: ITU G.993.2, ITU-T G.997.1 • VDSL2 Profile: 8a, 8b, 8c, 8d, 12a, 12b, 17a, 35b • ADSL2+: ITU-T G.992.5 • ADSL2: ITU-T G.992.3 • ADSL: ITU-T G.992.1(G.dmt), ITU-T G.992.2 (G.lite) |
| DSL Speed | Up to 350 Mbps |
| Standards and Protocols | IEEE 802.3, IEEE 802.3i, EEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, LLDP |
| Compatibility | VDSL2/ADSL2+/ADSL2/ADSL |
| Interface | • 1× RJ11 Ports • 4× RJ45 Gigabit Ports (1× WAN/LAN, 3× LAN) • 2× USB 2.0 Ports ((Supports USB LTE dongle and USB Storage*) |
| Button | Reset Button |
| Power Supply | 12V/2A external DC power adapter |
| Flash | 128 MB NAND |
| DRAM | 256 MB DDR |
| Dimensions ( W x D x H ) | 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) |
| Mounting | Desktop/Wall Mount |
| Max. Power Consumption | • Power adapter not included: 13.44 W • Power adapter included: 15.12 W |
| PERFORMANCE | |
|---|---|
| Concurrent Session | 50,000 |
| New Sessions /Second | 2,500 |
| NAT (Static IP) | • Upload: 945 Mbps • Download: 945 Mbps |
| NAT(DHCP) | • Upload: 945 Mbps • Download: 945 Mbps |
| NAT(PPPoE) | • Upload: 940 Mbps • Download:940 Mbps |
| NAT (L2TP) | • Upload: 703 Mbps • Download: 496 Mbps |
| NAT (PPTP) | • Upload: 703 Mbps • Download: 496 Mbps |
| 66 Byte Packet Forwarding Rate | • Upload: 727,679 pps • Download: 598,214 pps |
| 1,518 Byte Packet forwarding rate | • Upload: 76,147 pps • Download: 76,555 pps |
| IPsec VPN Throughput | • ESP-SHA1-AES256: 230 Mbps • ESP-SHA256-AES256: 233 Mbps • ESP-SHA384-AES256: 54 Mbps • ESP-SHA512-AES256: 34 Mbps |
| GRE | • Unencrypted: 623 Mbps • Encrypted: 205 Mbps |
| WireGuard VPN | 66 Mbps |
| OpenVPN | 15 Mbps |
| L2TP VPN Throughput | • Unencrypted: 433 Mbps • Encrypted: 175 Mbps |
| PPTP VPN Throughput | • Unencrypted: 511 Mbps • Encrypted: 44 Mbps |
| DPI Throughput | • TCP: 995 Mbps • UDP: 762 Mbps |
| Management Features | |
|---|---|
| Omada App | Yes. Require the use of an Omada Controller. |
| Centralized Management | • Omada Central (Cloud-Based) • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Require the use of an Omada Controller. |
| Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
| Maintenance | • Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute) • NTP Synchronize§ • Port Mirroring • CLI§ • Syslog Support • TR-069 (data models of TR-098 and TR181 are supported) |
| Zero-Touch Provisioning | Yes. Require the use of an Omada Controller. |
| Management Features | • Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration |
| BASIC FUNCTIONS | |
|---|---|
| LAN DNS | √ |
| WAN Connection Type | • Static IP • Dynamic IP • PPPoE (supports MRU Configuration) • PPTP • L2TP |
| MAC Clone | Modify WAN/LAN MAC Address‡ |
| DHCP | • DHCP Server • DHCPv6 PD Server§ • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP • WAN DHCP 60 |
| Stateful ACL | √ |
| Quality of Service | √ |
| Bridge VLAN | √ |
| mDNS Repeater | √ |
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| Advanced Features | |
|---|---|
| Advanced Routing | • Static Routing • Policy Routing • RIP§ • OSPF§ |
| Bandwidth Control | IP-Based Bandwidth Control |
| Load Balance | • Intelligent Load Balance • Application Optimized Routing • Link Backup(Timing, Failover) • Online Detection |
| NAT | • One-to-One NAT • Multi-Net NAT • Port Forwarding • Port Triggering§ • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP • Disable NAT |
| Session Limit | IP-Based Session Limit |
| AUTHENTICATION | |
|---|---|
| Web Authentication | • No Authentication • Simple Password • Hotspot (Local User / Voucher? / SMS? / Radius?) • External Radius Sever • External Portal Sever? • LDAP§ |
| OTHERS | |
|---|---|
| Network Services Enabled by Default | Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP _____________________________________________________ TDP Server Device discovery • Port: 20003 Protocol: UDP _____________________________________________________ VOIP Server Monitor SIP messages • Port: 5060 Protocol: UDP _____________________________________________________ DHCP Server Handle DHCP packets • Port: 67 Protocol: UDP _____________________________________________________ DNS Handle DNS packets • Port: 53 Protocol: TCP/UDP |
| Certification | CE, FCC, RoHS |
| Package Content | • DR3150 • Power Adapter • Ethernet Cable • Phone Cable • External Splitter • Mounting Feet • Quick Installation Guide |
| System Requirements | • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 • MAC OS, NetWare, UNIX or Linux |
| Environment | • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing |
