| CAMERA | |
|---|---|
| Image Sensor | 1/2.49” Progressive Scan CMOS |
| Shutter Speed | 0.075 to 1/20,000 s |
| Slow Shutter | Yes |
| Minimum Illumination | 0.005 Lux; 0 Lux with IR/White Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Auto |
| LENS | |
|---|---|
| Type | Fixed Focal Lens |
| Focal Length | 4 mm |
| Aperture | F1.6 |
| FOV | • Horizontal FOV: 101.5° • Vertical FOV: 49.2° • Diagonal FOV: 119.4° |
| Lens Mount | M12 |
| DORI Distance | 4 mm: • D: 400 ft (122 m) • O: 167 ft (51 m) • R: 82 ft (25 m) • I: 39 ft (12m) |
| Angle Adjustment (Manual) | |
|---|---|
| Range | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| ILLUMINATOR | |
|---|---|
| IR LED | • Quantity: 2 • Range: 98 ft (30 m) • IR Wavelength: 850 nm |
| White LED | • Quantity: 2 • Range: 98 ft (30 m) |
| Illuminator On/Off Control | Auto/Always on/Always off |
| VIDEO | |
|---|---|
| Max. Resolution | 4512x2512 |
| Main Stream | • Frame Rate: 50Hz: 25fps (4512x2512, 3840x2160, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720) 60Hz: 30fps (4512x2512, 3840x2160, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720) • Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. If supplement light is on, the frame rate only supports up to 20fps. |
| Sub-Stream | • Frame Rate: 50Hz: 25fps (840x480,704x576,640x480, 640x360, 352x288, 320x240) 60Hz: 30fps (840x480,704x576,640x480, 640x360, 352x288, 320x240) • Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. If supplement light is on, the frame rate only supports up to 20fps. |
| Bit Rate Control | CBR, VBR |
| Video Compression | • Main Stream: H.265+/H.265/H.264+/H.264 • Sub-Stream: H.265/H.264 |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | • Main Stream: 256 Kbps to 12288 Kbps • Sub-Stream: 64 Kbps to 1024 Kbps |
| Image | |
|---|---|
| Image Settings | • Mirror • Rotation • Contrast • Brightness • Saturation • Sharpness • Exposure • White Balance |
| Image Enhancement | BLC/3D DNR/SmartIR |
| Wide Dynamic Range | DWDR |
| SNR | ≥ 52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| OSD Setting | Yes |
| AUDIO | |
|---|---|
| Audio Communication | Two-Way Audio |
| Audio Input | Yes (Built-in Microphone) |
| Audio Output | Yes (Built-in Speaker) |
| Audio Compression | Yes |
| Audio Sampling Rate | 8KHz, 16KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64 Kbps(G.711 alaw, G.711 ulaw) |
| NETWORK | |
|---|---|
| Protocol | TCP/IP, UDP, ICMP, ARP, SMTP, RTMP, HTTP, HTTPS, DHCP, DNS, RTSP, RTP, NTP, IPv4, IPv6, UPnP, SSL/TLS, FTP/SFTP |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile G/S/T) |
| Simultaneous Live View | 3 Main Streams & 10 Sub-Streams |
| Client | Web UI, Omada Guard App, Omada Cloud-Based Controller (Guard) |
| Web Browser | • Google Chrome® 57 and above • Firefox® 52 and above • Safari® 11 and above • Microsoft® Edge 91 and above |
| Cloud | Yes |
| Security | Password Protection, HTTPS Encryption, IP/MAC Restriction, Digest Authentication, 802.1X Authentication |
| ALARM AND EVENT MANAGEMENT | |
|---|---|
| Event | • Motion Detection (Human Detection, Vehicle Detection, Pet Detection) • Line Crossing Detection • Intrusion Detection • Camera Tampering |
| Alarm Linkage | • Memory Card Video Recording • Upload to FTP Server • Push Notifications • Active Defence-Sound Alarm • Active Defence-Light Alarm • Email Alarm |
| INTERFACES | |
|---|---|
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Reset Button | Yes |
| Power | DC Power Port |
| On-board Storage | Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB* |
| Built-in Microphone | Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera |
| Built-in Speaker | Yes |
| GENERAL | |
|---|---|
| Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
| Storage Temperature | -40 °C to 60 °C (-40 °F to 140 °F) |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Storage Humidity | 95% or Less (Non-Condensing) |
| Package Content | • Omada Network Camera • Waterproof Cable Attachments • Network Cable (3 ft/1 m) • Mounting Template • Mounting Accessories • Screwdriver • GNU General Public License Notice • Installation Guide • Surveillance Sticker |
| Material | Metal |
| Net Weight | 0.6 Kg |
| Power Supply | DC • 12V DC ± 5%, Max. 11.4 W, 5.5 mm Coaxial Power Plug • Recommended Power Supply: T120150-2C1 (for EU Regions) PoE • PoE: 802.3af/at, Max. 12.9 W ErP Information • Power consumption in networked standby when all wired network ports are connected and all wireless network ports are activated: 5.3 W |
| Protection | • IP67 Weatherproof • IK10 Vandal Proof |
| Product Dimensions (L x W x H) | 8.3 × 2.9 × 3.1 in (210 × 74 × 78 mm) |
| Certifications | CE, NTRA, FCC, IP67, IK10, VCCI, BSMI, ONVIF |
