5G/4G/3G |
|
|---|---|
| Network Type | 5G: ]N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N75/N76/N77/N78 (2100/1800/850/2600/900/800/700/2600/2300/2500/1500/1500/3700/3500 MHz) 4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28/B32(2100/1800/850/2600/900/800/700/1500 MHz) TDD-LTE: B38/B40/B41/B42/B43(2600/2300/2500/3500/3700 MHz) 3G: DC-HSPA+/HSPA/UMTS:B1/B5/B8(2100/850/900 MHz) |
| Speed | 5G: Download Speed 4.67 Gbps Upload Speed 1.25 Gbps 4G LTE Cat19: Download Speed 1.6 Gbps Upload Speed 211 Mbps |
|
HARDWARE FEATURES |
|
|---|---|
| Interface | 1 × 2.5Gbps WAN/LAN Port (PoE In) 1 × Nano SIM Card Slot 1 × Type-C Port (only for debug) |
| Button | RESET Button |
| External Power Supply | Power: 48V/0.5A 802.3at PoE: 42-57V/0.6A |
| Dimensions ( W x D x H ) | 9.2 x 4.3 x 1.4 in (233x 110x 37 mm) |
| Antenna | Internal NR/LTE Antennas + Internal Wi-Fi Antennas |
|
SOFTWARE FEATURES |
|
|---|---|
| Quality of Service | Bandwidth Control |
| Operating Modes | 3G/4G/5G Router, Wireless Router |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Management Features | Access Control, Local Management, Remote Management, reboot schedule |
| DHCP | Server, DHCP Client List, Address Reservation |
| Port Forwarding | ALG, Virtual Server, Port Triggering, UPnP, DMZ |
| Dynamic DNS | TP-Link, DynDns, NO-IP |
| Firewall Security | DoS, IPv4 SPI Firewall, IPv6 Firewall, IP and MAC Address Binding, Access Control |
| Protocols | IPv4, IPv6 |
| Guest Network | 2.4 GHz guest network x 1, 5 GHz guest network x 1 |
| VPN Server | PPTP VPN, IPSec VPN, OpenVPN |
|
WIRELESS FEATURES |
|
|---|---|
| Wireless Standards | IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | 574 Mbps at 2.4 GHz, 2402 Mbps at 5 GHz |
| Reception Sensitivity | • 5 GHz: 11ax HE20: -64 dBm, 11ax HE20 MCS11 -64 dBm, 11ax HE20 MCS0 -94 dBm 11ax HE40: -61 dBm, 11ax HE40 MCS11: -61 dBm, 11ax HE40 MCS0 -91 dBm 11ax HE80: -59 dBm, 11ax HE80 MCS11: -59 dBm, 11ax HE80 MCS0 -89 dBm 11ac VHT20: -70 dBm, 11ac VHT20 MCS8: -70 dBm 11ac VHT40: -67 dBm, 11ac VHT40 MCS9: -67 dBm 11ac VHT80: -64 dBm, 11ac VHT80 MCS9: -64 dBm • 2.4 GHz: 11ax HE20: -66 dBm, 11ax HE20 MCS11: -66 dBm, 11ax HE20 MCS0 -94 dBm 11ax HE40: -62 dBm, 11ax HE40 MCS11: -62 dBm, 11ax HE40 MCS0 -91 dBm 11ac VHT20: -71 dBm, 11ac VHT20 MCS8: -71 dBm 11ac VHT40: -67 dBm, 11ac VHT40 MCS9: -67 dBm |
| Wireless Security | WPA/WPA2, WPA-PSK/WPA2-PSK, WPA3 encryptions |
| Wireless Function | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics |
| EIRP (CE) | ≤20dbm(2.4GHz) ≤23dbm(5G band1/band2) ≤30dbm(5G band3) |
|
OTHERS |
|
|---|---|
| Certification | CE, RoHS |
| Package Content | • 5G AX3000 Wi-Fi 6 Outdoor Router Archer NX500-Outdoor • 10-meter Flat RJ45 Ethernet Cable • PoE Adapter • AC Power Cord • Grounding Terminal • Quick Installation Guide • Window/Pole/Wall Mounting Kits |
| Requirements | • Edge, Firefox, Chrome, Safari, or other JavaScript-enabled browser *You are recommended to use the latest version • Nano SIM Card |
| Environment | • Operating Temperature: -30?~60? (-22°F~140°F) • Storage Temperature: -40°C~70°C (-40 °F~158 °F) • Operating Humidity: 5%~90% RH • Storage Humidity: 5%~90% RH |
