Silverstone SST-CS351 5-Bay Hot Swap Nas Chassis
Web ID: 38398
Hot-swap drive trays support up to five 3.5" or 2.5" SAS-12G / SATA-6G drives with two LED indicators for displaying drive status*
Drive tray features anti-theft lock design to keep confidential information secured
Supports 8 x 2.5" hard drive and up to 7 x 3.5" hard drives**
Accommodates Micro-ATX motherboard and ATX PSUs.
Supports up to 368mm (14.5") expansion cards**
Front I/O includes USB Type-C x 1, USB 3.0 x 2, combo audio x 1
Ample space for CPU cooling (82mm in height)
Manufacturer Warranty: 1 Year
Manufacturer PN: SST-CS351
Manufacturer Website
Model No.
SST-CS351
Material
Plastic front panel, galvanized steel body
Motherboard
Drive bay
External
- 3.5" / 2.5" SAS / SATA hot-swap x 5
Internal
- 3.5" x 2
2.5” (5 ~ 9.5mm) x 1 + 2.5” (15mm) x 7**
Cooling system
Rear
- 40mm x 3 (optional)
Top
- 80mm x 2 (optional)
Internal
- 80mm x 1
Limitation of CPU cooler
82mm
Expansion slot
4
Limitation of expansion card
368mm (14.5”) **
Power supply
Standard PS2 (ATX) (optional)
Limitation of PSU
160mm ***
Front I/O port
USB Type-C x 1
USB 3.0 x 2
Combo audio x 1
Dimension
265mm (W) x 209mm (H) x 411mm (D) , 25.1 Liters
10.43" (W) x 8.23" (H) x 16.18" (D) , 25.1 Liters
Net weight
5 kg
