Model No.

SST-RM47-502-I

Chassis Form Factor

4U

Material

Steel

Motherboard

SSI-EEB, SSI-CEB, Extended ATX, ATX, Micro-ATX, Mini-ITX

Drive bay

External

• 5.25" x 2 (downwards compatible with 2.5" SSD x 4 or 3.5" HDD x 2)

Internal

• 2.5" x 2

Cooling system

Front

• 80mm x 1 (80mm x 1 fan included)

Rear

• 120mm x 2 / 140mm x 2 / 160mm x 2*

Radiator support

Rear

• 120mm x 2 / 240mm x 1 / 280mm x 1

Limitation of CPU cooler

114mm (graphics card installed on standard height slots)
148mm (no graphics cards installed on standard height slots)

Expansion slot

8 low-profile + 3 standard height

Limitation of expansion card

Length : 437mm (without rear fans and radiator installed)
Width : Standard height expansion slots: 167mm
Low-profile height expansion slots: 142mm

Power supply

PS2 (ATX) / Mini Redundant / 2U Redundant / 2U 1+1 CRPS

Limitation of PSU

PSU + ODD / 5.25" device: 430mm

Front I/O port

USB Type-C x 1
USB 3.0 x 2

LED Indicators

Power LED x 1
HDD Access x 1
LAN LED x 2

Dimension

440mm (W) x 176mm (H) x 456mm (D), 35.3 Liters
17.32" (W) x 6.93" (H) x 17.95" (D), 35.3 Liters

Net weight

9.28 kg
