Model No.

SST-RM41-H08

Material

SGCC

Motherboard

SSI-CEB (12" x 10.5"), ATX (12" x 9.6"), Micro ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7")

Drive Bay

External

• 5.25" x 3

  3.5" x 5 (Hot-swappable)

Internal

• 3.5" x 4

  2.5" x 2 (Support up to 15mm)

  2.5" x 1 (Support up to 15mm) or slim optical drive (Support up to 12.7mm)

Expansion Slot

7 standard PCI / PCIe expansion slots

Front I/O Port

USB 3.1 Gen1 Type-A x 2

Power Supply

PS2 / ATX / Mini Redundant (supports up to 200mm)

Net Weight

10.7 kg

Dimension

430mm (W) x 176mm (H) x 446mm (D)

Chassis form factor

4U

Front buttons

Power On / Off, restart

Indicators

Power status x 1, system reset x 1, network status x 2

Main metal thickness

1.2mm

Expansion card

Length w/ 5.25” drive cage: 278mm
Length w/o 5.25” drive cage: 426mm

Limitation of CPU cooler

148mm

Cooling system

Front

• 80 x 25mm fan slot x 1

Rear

• 80 x 25mm fan slot x 2 (both fans included)

Internal

• 80mm fan x 1, 3000rpm (on hot-swap cage)

* Your system must have a SAS controller to use SAS hard drives
** For maximum supported capacity and drive array, please consult with your SAS or SATA drive manufacturer
*** RM41-H08 has 2 rows of slide rail locking holes. If you wish to fix it in the positive U position of the rack, please lock the rails in the sliding rail locking holes of the lower row of RM41-H08
