Model No.

SST-IM360-ARGB

Application

Intel LGA 115X/1200/1700/2011/2066
AMD socket AM5/AM4

Water block

Dimension

• 73mm (W) x 70mm (H) x 84mm (D)
  2.87" (W) x 2.76" (H) x 3.31" (D)

Material

• Copper base with plastic body

Pump

Motor speed

• 3,100 ±10% RPM

Rated Voltage

• 12V

Rated Current

• 0.38A

Connectors

• 2510 - 3 pin

Radiator

Dimension

• 120mm (W) x 28mm (H) x 396mm (D)
  4.72" (W) x 1.1" (H) x 15.6" (D)

Material

• Aluminum

Tube

Length

• 460mm

Material

• Rubber

Fan

Dimension

• 120mm (W) x 25mm (H) x 120mm (D)
  4.72" (W) x 0.98" (H) x 4.72" (D)

Speed

• 500 ~ 2,200 RPM

Noise level

• 12.1 ~ 33.1 dBA

Rated Voltage

• 12V

Max airflow

• 75.74 CFM

Max air pressure

• 3.4mmH₂O

Connector

• 4 pin PWM & 4-1 pin ARGB (5V LED)

Remark

* Please ensure that the control box and the RGB port on the motherboard you wish to connect are compatible with the RGB port definition of the IM360-ARGB. An incorrect connection may result in malfunctions or damage.
