Video Input Connectors

1x HDMI Type A 2.0

Video Passthrough Output

1x HDMI Type A 2.0

Max Input Resolutions (HDMI In)

4Kp60 HDR

1440p144 HDR

1080p240 HDR

Variable Refresh Rate Support (VRR)

Yes

Max Capture Resolutions

4Kp30

1440p60

1080p120

1080p60 HDR

Audio Input Connectors

1x XLR Combo Jack (Mic/Instrument)

1x Wireless Receiver

1x Input HDMI

Audio Output Connectors

1x 3.5 TRRS Headset Jack (I/O)

1x ¼" Headphone Jack

Input Dynamic Range

113dB

Preamp Noise

-131.5dBV (A-weighted)

Frequency Range

Microphone Inputs: 20Hz-20kHz

Headphone Output: 20Hz-20kHz

Microphone Input Impedance (Ω)

4KΩ

Instrument Input Impedance (Ω)

1MΩ

Preamplifier Gain Range

0-76dB

Phantom Power

Yes

Direct Monitor

Yes

Headphone Output Power

125mW per channel

Internal Storage (GB)

2GB (SMART Pads)

Power Requirements

Via USB: 5V @ 3A



Weight (grams)

380g

Dimensions (millimetres)

Length: 144mm

Width: 122mm

Height: 51mm



USB Interface

USB 1: USB 3.1 type C

USB 2: USB 2.0 type C

Bit Depth

24-bit

Sampling Rate (kHz)

48kHz

Processing

APHEX Processing

RØDE Voice FX

Minimum OS Requirements

macOS 10.15 or later

Windows 10 Version 1803 or later

Windows 11
