Frequency Range

Mic Inputs: 20Hz - 20kHz

Monitor Outputs: 20Hz - 20kHz

Microphone Input Impedance

4KΩ

Instrument Input Impedance

1MΩ

Preamplifier Gain Range

0 - 76dB

Equivalent Noise

-131.5dBV (A-weighted)

Line Output Maximum Level

4dBu

Headphone Output Power

250mW

Power Requirements

USB-C PD (9V, 3A)

Analogue Audio Input Connectivity

2 x combo jack (mic, instrument, line)

1 x 3.5 TRRS headset jack (I/O)

USB Interface 1

1 x 2-in/14-out multichannel device

1 x 2-in/2-out with mix-minus

USB Interface 2

1 x 2-in/2-out with mix-minus

Bit Depth

32 Bit (USB1)

24 Bit (USB2)

Sample Rate

48kHz

Recording Storage

microSDHC, microSDXC, USB-C removable drive (exFAT — minimum 100MB/s)

Data Transfer

USB 3.0 SD card reader 130MB/s

Network Connectivity

WiFi 802.11g/n/ac 2.4GHz and 5GHz, Ethernet 100/100

Internal Storage (GB)

4GB (SMART pads)

OS Requirements

macOS 10.15 or later, Windows 10 Version 1803 or later, Windows 11



Weight (grams)

1131

Dimensions (millimetres)

Length: 235

Width: 225

Height: 76
