Acoustic Principle

Permanently polarized

Active Electronics

JFET impedance converter

Acoustic Principle

Omnidirectional

Frequency Range

20Hz - 20kHz

Signal to Noise Ratio

67dB

Equivalent Noise Level (A-Weighted)

27dBA Typical

Maximum SPL

106dB SPL RMS (Plug-In Power, 1% THD) 123dB SPL RMS (Plug-In Power, 10% THD)

Maximum Output Level

307mV (@ 1kHz, 10% THD into 1KΩ load)

Sensitivity

38dB re 1 Volt/Pascal (12.59 mV @ 94 dB SPL) +/- 3 dB @ 1kHz

Dynamic Range

92dB @ max input

Connection Type

3.5mm bayonet jack (for NTH-100)

Weight (grams)

5

Dimensions (millimetres)

Length: 123

Height: 40

Depth: 17
