PHYSICAL SPECIFICATION

• Orbi Pro WiFi 6 Router (SXR80) : Dimensions6.8 x 3.3 x 9.7 in, Weight 2.06lb
• Orbi Pro WiFi 6 Satellite (SXR80) : Dimensions6.8 x 3.3 x 9.7 in, Weight 2.06lb each

TECHNICAL SPECS

• What do I need for Orbi Pro WiFi 6 to work? : 1. High-speed Internet connection 2. Connect to existing modem or gateway 3. Use the local UI to set up and customize in minutes
• WiFI Technology : (2,400 + 2,400 + 1,200) Mbps†, Simultaneous Tri-band WiFi
• Radio 1 : IEEE 802.11b/g/n/ax 2.4GHz - 256QAM support
• Radio 2 : IEEE 802.11a/n/ac/ax 5GHz - 1024QAM support
• Radio 3 : IEEE 802.11a/n/ac/ax 5GHz - 1024QAM support
• Antennas : Eight (8) high-performance antennas with high-power amplifiers
• MU-MIMO : OFDMA and bi-directional MU-MIMO WiFi 6 throughput. MU-MIMO capable for simultaneous data streaming on multiple devices
• TWT : TWT (Target Wait Time) for longer smartphone battery life
• Beamforming : Implicit/Explicit Beamforming for 2.4GHz and 5GHz bands
• Link Aggregation Grouping : Local Area Network Ports for Router Unit 4x GbE, of which two can be formed in a LAG. Local Area Network Ports for Satellite Unit 1x 2.5GbE; 4x GbE, of which two can be formed in a LAG
• Ports – Orbi Pro WiFI 6 Router : One (1) Gigabit or 2.5 Gigabit Ethernet WAN or LAN port. Two (2) Gigabit Ethernet LAN ports, Link Aggregation Mode4 optional. Two (2) Gigabit Ethernet LAN ports
• Security : Four (4) SSID wireless networks (Administration, Employee devices, Guest WiFi, IoT devices). Flexible VLAN configuration on all four (4) SSID WiFi networks. Client isolation by default on Guest SSID and configurable on other SSIDs. WPA/WPA2/WPA3 support.
• Local Admin : Local Admin UI available for extensive feature setting and maintenance
• Insight : Insight App - Secured Cloud for remote monitoring

SUPPORT & WARRANTY

• Orbi Pro WiFi 6 Router does not support and will not pair with Orbi Home or Orbi Pro (WiFi 5) WiFi System Satellites.
• ProSUPPORT OnCall 24x7 Service Packs3 : PMP0312-10000S
• PMP0332-10000S
• PMP0352-10000S
• Insight : 1-year subscription included
• 90-day complimentary technical support1 www.NETGEAR.com/support
• SXK80 Router + 1x Satellite
• SXK80B3 Router + 2x Satellite
• SXK80B4 Router + 3x Satellite
• SXS80 Satellite only

WHAT'S IN THE BOX

• One (1) Orbi Pro WiFi 6 Router (SXR80)
• One (1) Orbi Pro WiFi 6 Satellite (SXS80)
• Two (2) wall mounts with screws
• One (1) 2m Ethernet cable
• Two (2) 12V/3.5A power adapters
• Installation guide
