This product is no longer avaliable.
See suggested alternative models below.
The MSI ARSENAL GAMING (MAG) series is engineered to give gamers the edge they need to dominate on the virtual battlefield. Inspired by the rugged durability and unwavering reliability of military-grade equipment, the MAG series is built to provide an unwavering defense in every gaming scenario.
However, MAG isnt just about performance;its a design language that conveys ruggedness and toughness, embodying the very essence of the MAG style. For gamers who are determined to dominate their digital battlegrounds, the MAG series is here to stand with you, establishing the ultimate defense.
| Radiator Size |
360 mm |
| Radiator Dimensions (WxDxH) |
394 x 120 x 27 mm / 15.5 x 4.7 x 1.06 inches |
| Radiator Material |
Aluminum |
| Water Cooling Tube Material |
EPDM |
| Number of Fans |
3 |
| Fan Dimensions (WxDxH) |
120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches |
| Fan Air Flow |
70.7 CFM |
| Fan Bearing |
Loop Dynamic Bearing(LDB) |
| Fan Life Expectancy |
30,000 hrs@40? |
| Fan Rated Current |
0.2A (MAX:0.3A) |
| Fan Power Consumption |
2.4W (MAX:3.6W) |
| PWM Mode |
Yes |
| Cable Length (PWM Cable) |
550 / 500 mm; 21.65 / 19.69 inches |
| Fan Connector |
5V ARGB 3-PIN Header |
| Block Lighting |
ARGB Gen2 |
| Fan Lighting |
ARGB Gen2 |
| Pump Life Expectancy |
50,000 hours in typical use |
| Pump Noise Level |
20 dBA (avg.) |
| Pump Rated Current |
0.32A (Max: 0.5A) |
| Pump Power Consumption |
3.84W (Max: 6W) |
| Pump Speed |
3400 RPM ± 10% |
| Pump Connector |
PWM 4-PIN Header |
| 5V ARGB 3-PIN Header ( Female ) | |
| 5V ARGB 3-PIN Header ( male ) | |
| Cold Plate Material |
Copper |
| Block Dimensions (WxDxH) |
69.1 x 74 x 62.45 mm |
| Intel Socket Support |
LGA 1150/1151/1155/1156/1200/1700 + Next gen |
| AMD Socket Support |
AM5 / AM4 |
| Accessories |
Thermal paste x 1 |
3 Year
Manufacturers Warranty
Need a hand with something tech related? Our team put the human lingo in technology. Simply give us a call and we’ll be more than happy to assist!
PN: CL-W361-PL12SW-A
$115
