| Part Number |
952-000011 |
| Dimensions |
|
| Swytch Hub |
Height: 27.4 mm, Width: 164 mm, Depth: 90 mm |
| Swytch Extender |
Height: 27.4 mm, Width: 120 mm, Depth: 120 mm |
| Technical Specifications |
|
| PORTS AND INTERFACES |
|
| Swytch Hub |
Power, HDMI 2.0 to Display, HDMI 2.0 to Meeting Room Computer, USB 3.0 Type A to Conference Camera, USB 3.0 Type C to Meeting Room Computer, USB 3.0 Type C to Swytch Extender |
| Swytch Extender |
Power, USB 3.0 Type A to Swytch Hub, USB 3.0 Type C to Swytch Connector, USB 3.0 Micro B to Swytch Connector |
| Swytch Connector |
USB 3.0 Type A to laptops with Type A ports, USB 3.0 Type C to laptops with Type C ports |
| Mounts |
Swytch Hub: Compatible with Logitech PC Mount (not included), Swytch Extender: Mount through a 25 mm grommet hole or attach below the table with included hardware, Swytch Connector: Magnetic dock included |
| General Specifications |
Number of Meeting Room Displays: 1, Maximum Resolution and Frame Rate, Display: 4K/60 fps, Maximum Resolution and Frame Rate, Camera: 4K/30 fps, Laptop Audio for Local Sharing: Yes, Laptop Audio for Online Meetings: Yes (with services that support content sharing with system audio), Device Management: Remote monitoring and management via Logitech Sync |
| Compatibility |
Conference Cameras: Works with Logitech Rally and Rally Plus, Rally Bar, Rally Bar Mini, MeetUp, GROUP, and other conference cameras that connect via USB |
| |
Room Solutions: Microsoft Teams Rooms, Zoom Rooms, Also compatible with other room solutions that use USB-connected conference cameras and an HDMI-connected display. |
| Cabling |
Logitech Strong USB 10m, Logitech Strong USB 25m |
| Warranty Information |
2-Year Limited Hardware Warranty |
