| PERFORMANCE | |
| Processor |
Intel® Core™ i7-14700, 20C (8P + 12E) / 28T, Max Turbo up to 5.4GHz, P-core 2.1 / 5.3GHz, E-core 1.5 / 4.2GHz, 33MB |
| Graphics |
Integrated Intel® UHD Graphics 770 |
| Chipset |
Intel® Q670 Chipset |
| Memory |
2x 8GB SO-DIMM DDR5-5600 |
| Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable |
|
Max Memory |
|
| Storage |
512GB SSD M.2 2280 PCIe® 4.0×4 NVMe® Opal 2.0 |
|
Storage Support
|
Models with Intel® UHD graphics: Up to two drives, 2x M.2 SSD • M.2 SSD up to 2TB each |
| Card Reader |
3-in-1 Card Reader |
| Optical |
None |
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC233NL-VB2-CG codec |
| Speakers |
3Wx2 |
| Camera |
5.0MP + IR Hybrid |
| Microphone |
2x, Array |
| Power Supply |
180W 90% |
| DESIGN | |
|
Display
|
23.8" FHD (1920×1080) IPS Anti-glare 250nits, 60Hz, 72% NTSC, software low blue light, flick free, touch |
| Touchscreen |
10-point Multi-touch |
| Keyboard |
USB Traditional Keyboard, Black, English |
| Mouse |
USB Calliope Mouse, Black |
| Optional Bay |
None |
| Expansion Slots |
Models with Intel® UHD graphics: Three M.2 slots (one for WLAN, two for SSD) |
| Case Color |
Black |
| Stand |
UltraFlex V Stand |
| Mounting |
VESA mount |
| Form Factor |
AIO (23.8 inches) |
|
Dimensions (WxDxH)
|
Lowest in flat mode: 539.6 x 344.19 x 227.54 mm (21.24 x 13.55 x 8.96 inches) Highest in vertical mode: 539.6 x 252.60 x 472.00 mm (21.24 x 9.94 x 18.58 inches) |
|
Weight
|
Around 7.83 kg (17.3 lbs) |
| CONNECTIVITY | |
| Ethernet |
Integrated 100/1000M |
| WLAN + Bluetooth |
Intel® Wi-Fi® 6 AX201, 11ax 2×2 + BT5.2 |
| Rear Ports |
|
| Right Ports |
|
| Optional Right Ports (configured) |
1x card reader |
| Optional Ports (configured) |
None |
| SECURITY & PRIVACY | |
| Security Chip |
Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Fingerprint Reader |
No fingerprint reader |
| Physical Locks |
Kensington® Security Slot™, 3 x 7 mm |
| Chassis Intrusion Switch |
Chassis Intrusion Switch |
| Additional Security |
None |
| Other Security |
ThinkShutter camera cover |
| MANAGEABILITY | |
|
System Management
|
Non-vPro® |
| SERVICE | |
| Base Warranty |
3-year, Onsite |
| Included Upgrade |
None |
| CERTIFICATIONS | |
| Green Certifications |
|
| Other Certifications |
|
| Mil-Spec Test |
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Fungus, Solar Radiation, Contamination by Fluids, Salt Fog) |
| SOFTWARE | |
| Operating System |
Windows® 11 Pro, English |
| Bundled Software |
None |
| ACCESSORIES | |
| Bundled Accessories |
None |
