$79
Click & Collect
Low stock at Mt Gravatt
Delivery
Available for Fast Dispatch Low stock
Buy Now, Pay Later. T&Cs Apply
Deliver High Definition Dual-Monitor Video Performance from Remote Servers, Workstations and PCs to Client Devices for Power Users
| Model | TERA2220 Series |
| Max Number of Displays | 2 |
| Processor | TERA2220 |
| Form Factor | Low Profile |
| Board Physical Dimensions |
1 6.6 inches (length) 2 2.713 inches (height), single slot |
| Bus Type | PCI Express x1 (compatible with any xPCIe slots: x1, x4, x8, x16) |
| Imaging Performance | 130 Mpps |
| Maximum Resolution | One 3840x2160 (DP model only)* One 2560x1600 Two 1920x1200 |
| Max Application Frame Rate (with PCoIP Zero clients) | 60 fps |
| PCIe Video Ports (connect to Graphics outputs) | Two mini-DisplayPort |
| Memory Type | 512 MB DDR3 with ECC |
| Typical Board Power | 13W |
| Encryption | AES-128/AES-256 Suite B Ciphers (Workstation) |
| Recommended Zero Client Endpoints for Full Functionality | TERA2321 or TERA2140 |
| Connectors | Two mini-DisplayPort connectors |
| Ethernet connector or Fiber connector | |
| Power Button Cable connector (optional for Remote Power Management) | |
| Thermal Cooling Solution | Passive heat sink |
| Operating System Support | Completely operating system independent |
| System Requirements | PCI Express compliant motherboard with one x1/x4/x8/x16 slot (Full height for TERA2240 and full/half height for TERA1202/2220) |
| PC/workstation with 1 or 2 graphics cards | |
| For 2560x1600 resolution, graphics card port must be DisplayPort (dual-link DVI is not supported) | |
| 10/100/1000 Mbps Ethernet LAN or 100/1000 Mbps Fiber switch/router | |
| Package Content | PCoIP host card |
| One or two DVI to mini-DisplayPort cables (Optional) | |
| One or two DisplayPort to mini-DisplayPort cables (Optional) | |
| One or two mini-DisplayPort to mini-DisplayPort cables (Optional) | |
| Power Button cable x 1 (optional for Remote Power Management) | |
| Additional Low Profile bracket x 1 | |
| Quick installation guide |
1 Year
Manufacturers Warranty
