Warranty

2 Year Limited

Host Connector

2 - USB-C® Male

Video Output

1 - HDMI™ Female
1 - DisplayPort™ Female

Power Source

Bus-powered

Network Interface

RJ45 (Gigabit Ethernet)

Audio Supported

Yes

Ports

• 1 - M.2 NVMe® /SATA Slot (2230,2242,2260,2280)
• 1 - USB-C® 3.2 Gen 2
• 1 - USB-C® Power Delivery 3.0
• 2 - USB™ Type-A 3.2 Gen 2
• 1 - USB™ Type-A 3.2 Gen 1
• 1 - 4K HDMI™
• 1 - 4K DisplayPort™
• 1 - SD™ & microSD™ 3.0 memory card reader/writer
• 1 - RJ45 Gigabit Ethernet
• 1 - Security Lock Slot

Maximum Display Resolution

3840 x 2160

Maximum Display Refresh Rate

60

Maximum Data Transfer Rate

10 Gbps
M.2 slot - Write: 900 MB/s, Read: 925 MB/s

Maximum Displays Supported

2

Compatible Networks

10/100/1000 Mbps

Audio Channel

2.1 via HDMI™ / 3.5 mm Aux

Power Delivery

Up to 100W via USB-C®

Power Consumption

≤ 600 mA

Input Current

5A

Input Voltage

20V

Output Current

5A

Output Voltage

20V

Color

Grey & Black

Enclosure Type

Aluminum

Cable Length

0.6 in. (15 cm)

Product Height

1.02 in. (26 mm)

Product Width

3.14 in. (80 mm)

Product Depth

12.5 in. (318 mm)

Product Weight

0.83 lbs. (378g)

Storage Temperature

14 to 149°F (-10 to 65°C)

Storage Humidity

< 85% non-condensing

Operating Temperature

32 to 118°F (0 to 48°C)

Operating Humidity

< 85% non-condensing
