IPEVO VZ-R Ultra 13MP Dual Mode Document Camera
Web ID: 46027
Ultra-Clear Image Quality with 13-Megapixel Sensor
Super Macro Focus 0.39 inches / 1 cm
Capture High-Speed Motion
3840 x 2160p @30fps
AI Noise Reduction
Built-in Microphone
Plug and Play
Point to Detail with Freehand Capturing
Manufacturer Warranty: 3 Year
Manufacturer PN: VZ-R Ultra
GTIN: 4712098411823
Manufacturer Website
$599
| Size & Weight | |
| Dimension | D x W x H (when folded): With base-4.57”x 4.25” x 11.85” (11.6 x 10.8 x 30.1cm), Without base-3.07” x 1.57” x 11.42” (7.8 x 4.0 x 29.0cm) |
| Weight | 2.2 lbs (1 kg) |
| Model and Color | |
| Model | CDVH-05IP |
| Color | Black |
| Camera | |
| Sensor | 1/3.06" CMOS |
| Max resolution | 4096 x 3072 |
| Lens type | Auto Focus |
| Focal length | 3.46 mm |
| Aperture | 2.2 |
| FOV | DFOV: 80 |
| Max capture area | 17.9" x 10.1" (455 x 256mm) [16:9], 18.9" x 14.4" (480 x 366mm) [4:3] |
| Shutter time | 1/7.5 ~ 1/30000 sec |
| WDR | N/A |
| Zoom | 1x ~ 4x (Digital), 1x ~ 20x (via Visualizer) |
| Microphone | |
| Type | Omni-directional microphone |
| Audio compression | PCM |
| Pick up range | 30 ~ 70cm |
| SNR | 60 dB |
| Frequency range | 48K 1ch-16bit PCM |
| Video | |
| Video compression | MJPG, YUV |
| Max frame rate | 4096 x 3072 @15 fps, 3264 x 2448p @30fps, 3840 x 2160p @30fps, 1920 x 1080p @60fps, 1920 x 1080p @30fps (Default) |
| Power | |
| Power input | DC 5V / 0.9A (USB - C connector) |
| Power consumption | 5V / 0.5A (max) |
| Environmental requirements | |
| Operating temperature | 32°F to 104°F (0°C to 40°C) |
| Storage temperature | 14°F to 122°F (-10°C to 50°C) |
| Humidity | 10% to 95% |
| Connectivity | |
| USB-C (UVC/UVA), HDMI | |
| Compatibility | Windows: Win 8 and above / Standard UVC, MAC: macOS 10.13 and above, Chrome OS & Chrome OS Flex: The latest version, Android: Ver.11 and above |
| The IPEVO camera is recognized by the IPEVO Visualizer app on iPadOS 17 and later with a USB-C iPad. It can also be detected by apps like FaceTime, Teams, and Zoom that support external cameras. If the app doesn't support external camera detection, the camera may not be recognized. | |
| Package Contents | |
| IPEVO VZ-R ULTRA, USB-A to USB-C Cable (4.92 ft / 1.5 m), Base, Screwdriver x 1, Screw x 4, Quick start guide | |
| Warranty | 3 years from the date of purchase. For more warranty information, please click here. |
