CPU Specifications

Total Cores

20

# of Performance-cores

8

# of Efficient-cores

12

Total Threads

20

Max Turbo Frequency Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Max Turbo Frequency" data-target=".upe-modal" data-title="Max Turbo Frequency" data-toggle="modal" type="button">

5.5 GHz

Intel® Turbo Boost Max Technology 3.0 Frequency ^‡ Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Intel® Turbo Boost Max Technology 3.0 Frequency ^‡" data-target=".upe-modal" data-title="Intel® Turbo Boost Max Technology 3.0 Frequency ^‡" data-toggle="modal" type="button">

5.5 GHz

Performance-core Max Turbo Frequency Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Performance-core Max Turbo Frequency" data-target=".upe-modal" data-title="Performance-core Max Turbo Frequency" data-toggle="modal" type="button">

5.4 GHz

Efficient-core Max Turbo Frequency Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Efficient-core Max Turbo Frequency" data-target=".upe-modal" data-title="Efficient-core Max Turbo Frequency" data-toggle="modal" type="button">

4.6 GHz

Performance-core Base Frequency Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Performance-core Base Frequency" data-target=".upe-modal" data-title="Performance-core Base Frequency" data-toggle="modal" type="button">

3.9 GHz

Efficient-core Base Frequency Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Efficient-core Base Frequency" data-target=".upe-modal" data-title="Efficient-core Base Frequency" data-toggle="modal" type="button">

3.3 GHz

Cache

30 MB Intel® Smart Cache

Total L2 Cache

36 MB

Processor Base Power

125 W

Maximum Turbo Power

250 W

Intel® Deep Learning Boost (Intel® DL Boost) on CPU

Yes

AI Software Frameworks Supported by CPU

OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

CPU Lithography

TSMC N3B

Supplemental Information

Marketing Status

Launched

Launch Date

Q4'24

Embedded Options Available

No

Use Conditions PRQ report.
For current use condition information, see Intel UC (CNDA site)*." data-keyboard="true" data-search-href="" data-search-icon="true" data-search-title="Find products with Use Conditions" data-target=".upe-modal" data-title="Use Conditions" data-toggle="modal" type="button">

PC/Client/Tablet

Memory Specifications

Max Memory Size (dependent on memory type)

192 GB

Memory Types

Up to DDR5 6400 MT/s

Maximum Memory Speed

6400 MHz

Max # of Memory Channels

2

NPU Specifications

NPU Name^‡

Intel® AI Boost

NPU Peak TOPS (Int8)

13

Sparsity Support

Yes

Windows Studio Effects Support

Yes

AI Software Frameworks Supported by NPU

OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

Expansion Options

Direct Media Interface (DMI) Revision

4

Max # of DMI Lanes

8

Intel® Thunderbolt™ 4

Yes

Scalability

1S Only

PCI Express Revision

5.0 and 4.0

PCI Express Configurations ^‡

Up to 1×16+2×4, 2×8+2×4,
1×8+4×4

Max # of PCI Express Lanes

24

Package Specifications

Sockets Supported

FCLGA1851

Thermal Solution Specification

PCG 2020A

Max Operating Temperature

105 °C

Advanced Technologies

Intel® Volume Management Device (VMD)

Yes

Intel® Gaussian & Neural Accelerator

3.5

Intel® Thread Director

Yes

Intel® Speed Shift Technology

Yes

Intel® Turbo Boost Max Technology 3.0 ^‡

Yes

Intel® Turbo Boost Technology ^‡

2.0

Intel® 64 ^‡

Yes

Instruction Set

64-bit

Instruction Set Extensions

Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States

Yes

Enhanced Intel SpeedStep® Technology

Yes

Thermal Monitoring Technologies

Yes

Security & Reliability

Intel® Standard Manageability (ISM) ^‡

Yes

Intel® Control-Flow Enforcement Technology

Yes

Intel® AES New Instructions

Yes

Secure Key

Yes

Intel® Trusted Execution Technology ^‡

Yes

Execute Disable Bit ^‡

Yes

Intel® OS Guard

Yes

Intel® Boot Guard

Yes

Mode-based Execute Control (MBEC)

Yes

Intel® Virtualization Technology (VT-x) ^‡

Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ^‡

Yes

Intel® VT-x with Extended Page Tables (EPT) ^‡

Yes
