Audio: 5.1 Channel
Audio Connection: RCA || Optical || 3.5mm
| Specification | Details |
|---|---|
| Driver | WHQL for Windows Driver, Support ASIO 2.3, WASAPI |
| Weight | 263g / 9.28 oz |
| Dimensions | 179 x 126 x 18 mm |
| Direct Mode | Line Out (Stereo): PCM 16-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0, 352.8, 384 kHz Line Out (Stereo): PCM 24-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0, 352.8, 384 kHz Line Out (Stereo): PCM 32-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0, 352.8, 384 kHz Coaxial SPDIF Out: PCM 16-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz Coaxial SPDIF Out: PCM 24-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz |
| DSD Playback | Headphone/Line Out (Stereo): Native DSD: DSD64, DSD128, DSD256 Front panel Headphone-out: Native DSD: DSD64, DSD128 |
| Playback Resolution | PCM 16-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0, 352.8, 384 kHz PCM 24-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0, 352.8, 384 kHz PCM 32-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0, 352.8, 384 kHz |
| Recording Resolution | TOSLINK SPDIF-in: Stereo, 16-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz TOSLINK SPDIF-in: Stereo, 24-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz Front panel Mic-in: Dual-mono, 16-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz Front panel Mic-in: Dual-mono, 24-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz Line-in (Stereo): Stereo, 16-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz Line-in (Stereo): Stereo, 24-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz Mic-in: Dual-mono, 16-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz Mic-in: Dual-mono, 24-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz |
| Front Panel Headphone Out (Stereo) | PCM 16-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz PCM 24-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz PCM 32-bit, 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz |
| Platform | PCI-e |
| Connectivity Options (Main) | 1 x HD Audio Front Panel Connector 1 x ?" Headphone port 1 x RCA Line-out (Left) port 1 x RCA Line-out (Right) port 1 x Coaxial SPDIF-out port 1 x ?" Mic in/Line-in port 1 x TOSLINK SPDIF-in port |
| Headphone Amp | Output Impedance: 1Ω Supported Headphone Impedance: 8–600Ω IEM: 0.5Vrms Low: 1.5Vrms Mid: 3Vrms High: 6Vrms Maximum output power: 350mW @ 32Ω (High) Maximum output voltage: 6Vrms (High) |
| Front Panel Headphone Amp | Output Impedance: 10Ω Supported Headphone Impedance: 32–300Ω Maximum output power: 40mW @ 32Ω Maximum output voltage: 1.9Vrms |
| Supported Operating Systems | Windows® 10 Windows® 11 |
| Included Accessories | 1 x 3.5 mm CTIA TRRS to Dual TRS Headset Splitter Cable |
| Digital Filter | 8 pre-programmed filters |
| DAC | THD+N: 0.0001% Dynamic Range: 130 dB |
| ASIO | ASIO 2.3 |
| ADC | THD+N: 0.0006% Dynamic Range: 114 dB |
| System Requirements | Windows: Intel® Core™ i3 or AMD® equivalent x86 processor x86 compatible motherboard Microsoft® Windows 10 64-bit / Windows 11 64-bit 8GB RAM Available PCIe slot Internet connection for Software Download |
| Package Contents | 1 x Sound Blaster AE-X sound card 1 x 3.5 mm CTIA TRRS to Dual TRS Headset Splitter Cable 1 x Quick start guide & Compliance information & Warranty leaflet |
