USB Interface

• USB-C for power and data

Input

• 2 x XLR/ 1/4” Combo (Mic/Line/ Instrument)
• 1 x TRRS 3.5 mm (1/8”) Mobile stereo I/O

Output

• 2 x 1/4” Headphone out
• 1 x 1/4” Balanced/Unbalanced Stereo Out

Supported Recording and Playback Resolution *

• Playback - 16/24-bit, 44.1 kHz, 48.0 kHz, 96.0 kHz
• Recording - 24-bit, 44.1 kHz, 48.0 kHz, 96.0 kHz

*Playback and recording must be set at the same sampling rate

Frequency Response

• 20 - 45,000 Hz

Microphone Gain

• Up to 50 dB

Dynamic Range

• > 90 dB

Total Harmonic Distortion (THD)

• 0.05%

Dimensions (L x D x H)

• 187.7 x 109.2x 52.7 mm / 7.38 x 4.30 x 2.07 inches

Weight

• 890g (31.4 oz)

SYSTEM REQUIREMENTS

Windows

• Intel® i3 or AMD® Ryzen equivalent processor
• Intel, AMD, or 100% compatible motherboard
• Microsoft® Windows 11 / 10, 32 / 64-bit ver 1903 or higher
• 4 GB RAM
• > 4 GB of free hard disk space
• Available USB 2.0 / USB 3.0 port

Mac

• Mac running macOS 10.15 or later
• 4 GB RAM
• > 4 GB of free hard disk space
• Available USB 2.0 / USB 3.0 port

PACKAGE CONTENTS

• Creative Live! Audio A3
• USB-C to USB-A Cable for power and data
• Quick Start Leaflet
• Warranty Card

WARRANTY

2-year Limited Hardware Warranty (EU Countries)

1-year Limited Hardware Warranty (Non-EU Countries)
