| Specifications |
|
| Specifications |
|
| Hide |
|
| Barcode |
4549292150872 |
| Print |
|
| Hide |
|
| Printing Resolution (Horizontal X Vertical) |
4800 x 1200 dpi |
| Print Speed |
B&W: 13 ipm, Colour: 6.8 ipm |
| Ink Type |
Permanent (Refillable ink tanks) |
| Borderless Printing |
Top/Bottom/Right/Left margin: each 0 mm
(Supported Paper Size: A4/LTR/4"x6"/5"x7"/8"x10"/Square (5" x 5", 4«x4«, 89x89mm) |
| Bordered Printing |
Top margin: 3 mm, Bottom margin: 5 mm,
Left/Right margin: each 3.4 mm (LTR/LGL: Left: 6.4 mm, Right: 6.3 mm) |
| Paper Capacity |
Rear Tray: Max 20 sheets (photo paper) or 100 sheets (plain paper). Cassette: Max 350 sheets (plain paper) |
| Paper Sizes |
4" x 6", 5" x 7", 8" x 10", A5, A4, B5, Custom size (width 55mm – 215.9mm, length 89mm – 676mm), Envelope (DL, COM10), Square (5”x5”)*30 |
| Supported Paper Weights |
Plain Paper: 64-105 g/m2 , Canon specialty paper: max paper weight : up to 300 g/m2 (Photo Paper Plus Glossy II PP-201) |
| Network |
|
| Hide |
|
| Protocol |
TCP/IP, SNMP |
| Wireless Lan Network Type |
IEEE802.11n/IEEE802.11g/IEEE802.11b |
| Frequency Band / Channel |
2.4GHz, 1-13 |
| Wireless Lan Range |
indoor 50m (depend on the transmission speed and conditions) |
| Security |
WEP64/128bit, WPA-PSK(TKIP/AES),WPA2-PSK(TKIP/AES) |
| Mobile Phone/Tablet Printing |
Available |
| Camera/Memory Card Printing |
N/A |
| Pc Interface |
Available |
| Copier |
|
| Hide |
|
| Speed |
sFCOT/ Colour Simplex Approx. 20 sec
sESAT / Colour Simplex Approx. 5 sec |
| Multiple Copy |
Max 99 pages (black/ colour) |
| Scanner |
|
| Hide |
|
| Scanner Type |
Flatbed |
| Scanning Resolution |
Optical: 1200 x 2400 dpi |
| Scanning Speed |
A4 Colour/ 300 dpi – Approx. 3.5ms/line. A4 Greyscale: 300 dpi – Approx 1.5ms/line |
| Scanning Bit Depth (Input/ Output) |
Grayscale; 16bit/8bit Colour: RGB each 16bit/8bit |
| General Features |
|
| Hide |
|
| Interface |
High Speed USB |
| Paper Feed |
Rear Tray and Cassette |
| Power Source |
AC100 - 240V, 50/60Hz |
| Power Consumption |
Standby (scanning lamp is off) USB connection to PC: approx. 0.8W, OFF. (All ports connected) Approx. 1.7W OFF.
Copying (USB connection to PC) approx. 15W |
| Operating Environment |
Temperature: 5-35°C
Humidity: 10 - 90%RH (no dew condensation) |
| Dimensions (W X D X H) |
Approx. 403 x 369 x 195 mm |
| Weight |
Approx. 8.1kg |
| Quiet Mode |
Available |
| Notes |
|
| Hide |
|
| Print Speeds |
Document Print Speeds are averages of EAST in Office Test of the default simplex mode, ISO/IEC 24734, Print speed may vary depends on system configuration, interface software, document complexity, print mode, page, coverage, type of paper used etc |
| Print Speeds |
Ink droplets can be placed with a pitch of 1/4800 inch at minimum. |
| Scanning Resolution |
Paper types NOT supported for borderless printing are as follows: Envelope, High Resolution Paper, T-Shirt Transfer, Photo Stickers |
| Scanning Speed |
TWAIN driver (ScanGear) is based on the TWAIN specification V1.9 and requires the Data Source Manager comes with the operating system |
| Copy Speeds |
Copy Speeds are the average of sFCOT and sESAT, ISO/IEC29183, Copy speed may vary depending on document complexity, copy mode, page coverage, type of paper used etc.. and does not take into account warming-up time. |
| Copy Speeds |
Optical resolution is a measure of maximum hardware sampling resolution, based on ISO 14473 standard |
| Frequency Band / Channel |
The fastest speed in Hi-Speed USB on Windows PC. Transfer time to computer is not included |
