Basic Specs
Functions
Print, Scan, Copy, Fax
Printer Type
Laser Printer
Print Speed
Up to 50 (A4) / Up to 52 (Letter) ppm
Paper Type
Plain Paper, Letterhead, Colored Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env. Thin, Env.Thick
Paper Size
A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195×270 mm), A4 Short (270mm Paper), COM-10, DL, C5, Monarch
Maximum Paper Capacity
Up to 1,660 sheets of 80 gsm plain paper (with Added Optional Trays)
Resolution
Up to 1200 x 1200 dpi
2-Sided (Duplex) – Printing Paper Type
Plain Paper, Letterhead, Colored Paper, Thin Paper, Recycled Paper
2-Sided (Duplex) – Paper Size
A4
Paper handling
Tray #1 – Maximum Paper Capacity
Up to 520 sheets of 80 gsm plain paper
Tray #2 – Maximum Paper Capacity
LT-5505: Up to 250 sheets of 80 gsm plain paper
LT-6505: Up to 520 sheets of 80 gsm plain paper
Multi-purpose Tray – Maximum Paper Capacity
Up to 100 sheets of 80 gsm plain paper
Automatic Document Feeder (ADF) Maximum Paper Capacity
Up to 70 sheets of 80 gsm plain paper
Paper Output
Up to 150 sheets of 80 gsm plain paper (face-down delivery to the face-down output paper tray)
1 sheet (face up delivery to the face up output tray)
Copy
Enlarge/ Reduce
25% to 400% (in increments of 1%)
Resolution
Up to 1200 x 600 dpi
Scan
Resolution – Interpolated
Up to 19200 x 19200 dpi (interpolated) (Windows Only)
Resolution – Scanner Glass
Up to 1200 x 1200 dpi
Resolution – Automatic Document Feeder (ADF)
Up to 600 x 600 dpi
Fax
Compatibility
ITU-T Super G3
Modem Speed
33.6 Kbps
Memory Transmission
Up to 500 pages (ITU-T Test Chart #1, Standard Resolution, JBIG)
Out of Paper Reception
Up to 500 pages (ITU-T Test Chart #1, Standard Resolution, JBIG)
Connectivity
Connectivity
Hi-SpeedUSB2.0, Ethernet 10Base-T/100Base-TX/1000Base-T, IEEE 802.11a/b/g/n (Infrastructure Mode), IEEE 802.11a/g/n (Wi-Fi Direct)
Network
Wireless Network Security
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES)
*Wi-Fi Direct supports WPA2-PSK (AES) only.
Wireless Setup Support Utility – WPS
Yes
Display & Memory
Display Type
5.0" Colour Touchscreen LCD
Memory Capacity
512 MB
Operation
Power Source
220 – 240 V AC 50/60 Hz
Power Consumption – Ready
Approximately 31 W
Power Consumption – Sleep
Approximately 6.0 W
Power Consumption – Power Off
Approximately 0.05 W
Supported Operating Systems
Supported OS
Windows 10,11, Server 2012 / 2012 R2 / 2016 / 2019 / 2022
