Display

Brightness (ANSI lumens)

5500

Resolution

WUXGA (1920x1200)

Native Aspect Ratio

16:10

Contrast Ratio (FOFO)

3,000,000:1

Display Color

30-bit (1.07 billion colors)

Light Source

Laser

Light Source Life

20000 hrs

Optical

Throw Ratio

0.81 ~ 0.89

Zoom Ratio

1.1x

Lens

F/# = 1.83 ~ 1.86,f = 8.6 ~ 9.4 mm

Projection Offset (Full-Height)

0%

Keystone Adjustment

2D, Vertical ± 30 degrees; Horizontal ± 30 degrees

Lens Shift Vertical

Vertical: -60%~ +60% Horiztonal : -23%~ +23%


Rec. 709 Coverage

92%

Picture Modes

3D, Bright, Golf, Presentation, sRGB, User 1, User 2

Compatibility

Input Lag

33.4 ms (1080p@60Hz)

Resolution Support

VGA (640 x 480) to 4K UHD (3840 x 2160)

Horizontal Frequency

15K~102KHz

Vertical Scan Rate

23~120Hz

I/O Interface

PC in (D-sub 15pin)

(x1), PC in-1

Monitor out (D-sub 15pin)

(x1)

HDMI in

(x2), HDMI-1 (2.0a/HDCP2.2), HDMI-2 (2.0a/HDCP2.2)

LAN (RJ45)

(x1)

HDBaseT (RJ45)

(x1), Video/Audio

3D Sync in

(x1)

3D Sync out

(x1)

USB Type A

(x1), USB Type A-1 (2.0/Power Supply1.5A)

RS232 in (DB-9pin)

(x1)

Wired Remote in (3.5mm Mini Jack)

(x1)

DC 12V Trigger (3.5mm Jack)

(x1)

Audio

Speaker

(x2), 10W

Audio in (3.5mm Mini Jack)

(x1)

Audio out (3.5mm Mini Jack)

(x1)

Environment

Operating Temperature

0~40?

Power Supply

AC 100 to 240 V, 50/60 Hz

Typical Power Consumption (110V)

440W

Stand-by Power Consumption

<0.5W

Network Stand-by Power Consumption

<2W

Accessories

Remote Control w/ Battery

RCA011

Power Cord (by region)

x1 (1.8M)

3D Glasses

(Optional), DGD5

Installation Guide

1 (8L)

Warranty Card (by region)

Yes

Universal Ceiling Mount

(Optional), CM00G3

Dimension & Weight

Dimensions (WxHxD) (mm)

416x166 x 351 mm

Net Weight (kg)

7

Projection System

Projection System

DLP
