Display

• Brightness (ANSI lumens)

  500

• Resolution

  1080P (1920x1080)

• Native Aspect Ratio

  16:9

• Contrast Ratio (FOFO)

  100,000:1

• Display Color

  24-bit (16.7 million colors)

• Light Source

  Laser

• Light Source Life

  a. Normal 20000 hrs, b. ECO 30000 hrs

Optical

• Throw Ratio

  1.2

• Zoom Ratio

  Fixed

• Lens

  F/#=1.9; f=19.65mm

• Projection Offset (Full-Height)

  100%

• Keystone Adjustment

  2D, (Auto) Vertical ± 20 degrees, Horizontal ±30 degrees, Rotation ± 30 degrees(distance to the wall by projection direction: within 2M); 2D, (Manual) Vertical & Horizontal & Rotation ± 40 degrees


• Rec. 709 Coverage

  92%

• Picture Modes

  Custom, HDR Custom, HDR Night Shift, HDR Vibrant, HLG Custom, Night Shift, Vibrant, Bright, Cinema, Game, HDR Cinema, HDR Game, HLG

Compatibility

• Input Lag

  22.4ms (1080P 60Hz)

• Resolution Support

  VGA (640 x 480) to 4K UHD (3840 x 2160)

• Horizontal Frequency

  15K~135KHz

• Vertical Scan Rate

  23~62Hz

I/O Interface

• HDMI in

  (x1), HDMI-1 (2.0b/HDCP2.3)

• USB Type A

  (x1), USB Type A-1 (2.0/Power Supply1.0A/Reader/FW Upgrade)

• USB Type C

  Display Port/ PD in 20V-2.25A to 5A/ PD out 5V-2A, 9V-2A, 12V-1.5A, 15V1.2A/ Reader, (x1)

Audio

• Speaker

  (x2), 4W

• Woofer

  10W Chamber

• Audio out (3.5mm Mini Jack)

  (x1)

• HDMI Audio Return

  ARC, 5.1 channel

Environment

• Operating Temperature

  0~40?

• Power Supply

  AC 100 to 240 V, 50/60 Hz

• Typical Power Consumption (110V)

  85W@100 ~ 240VAC

• Stand-by Power Consumption

  <0.5W

• Network Stand-by Power Consumption

  <2W

• Acoustic Noise (Typ./Eco.)(dB)

  28dBA/26dBA

Accessories

• Carry Bag

  (Optional)

• Remote Control w/ Battery

  RCI078

• Power Cord (by region)

  x1 (1.8M)

• Quick Start Guide

  (x1) 1L

• Warranty Card (by region)

  Yes

Onscreen Display

• Launcher

  Smart Home

Smart System

• Built-in OS

  Yes, Google TV (Android 11)

• Bluetooth

  Yes, Bluetooth 5.0

• Wi-Fi Standard

  802.11 a/b/g/n/ac (2.4G/5G)

• Wireless Projection

  AirPlay, Google Cast

• Preload Apps

  BenQ Projector Assistant/ Screen Sharing for iOS/ BenQ Notification/ BenQ User Dashboard/ BenQ Remote Control Updater/ VLC

Dimension & Weight

• Dimensions (WxHxD) (mm)

  130.0 x 211.2 x 191.4

• Net Weight (kg)

  2.1

• Dimensions (WxHXD) (inch)

  5.12 x 8.31 x 7.54

• Net Weight (lb)

  4.6

Projection System

• Projection System

  DLP
