ASUS S1200 ATX TUF GAMING H470-PRO (WI-FI) DDR4 Motherboard

Web ID: 28289

Only compatible with NEW Intel 10th Gen Comet Lake CPU, Intel Socket 1200, Intel H470 Chipset, 1 x PCIe 3.0 x16 (x16 mode), 1 x PCIe 3.0 x16 (x4 mode), 3 x PCIe x1, 1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode), 1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode), 5 x SATA 6Gb/s ports, Rear USB Port (Total 6): 2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C), 2 x USB 3.2 Gen 1 ports (2 x Type-A), 2 x USB 2.0 ports, Front USB Port (Total 6): 1 x USB 3.2 Gen 2 front panel connector port(s)(1 x USB Type-C), 1 x USB 3.2 Gen 1 ports (2 x Type-A), 1 x USB 2.0 ports (2 x Type-A), 1 x USB 2.0 ports (1 x Type-A), 1 x DisplayPort 1.4, 1 x HDMI 1.4b, Intel I219-V 1Gb Ethernet, Intel Wi-Fi 6 AX201, Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC, ATX Form Factor
Manufacturer Warranty: 3 Year
Manufacturer PN: TUF GAMING H470-PRO (WI-FI)
GTIN: 192876720370
Manufacturer Website

$289SAVE $40

DURABLE. STABLE. RELIABLE.

TUF Gaming H470-PRO (WiFi) distills essential elements of the latest Intel® platform and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive set of cooling options, this motherboard delivers rock-solid performance with unwavering gaming stability.

When you build with a TUF Gaming motherboard, you also benefit from the TUF Gaming Alliance — an ASUS collaboration with trusted industry partners that ensures easier building, best compatibility, and complementary aesthetics from components to case.

chipset-H470-10thgenic-10thgen-su-rgb-3000

TUF Z390 Plus Gaming

TUF H370 Plus Gaming

  • Display Port

  • HDMI Port

  • USB 3.2 Gen 2 Type-C™

  • USB 3.2 Gen 2

  • USB 3.2 Gen 1

  • Intel I219-V LAN
    Turbo LAN Utility

  • Intel® Wi-Fi & BT 5.1

  • Audio

  • 2 x PCIe X16 Slots
    Intel® Rapid Storage Technology for CPU-attached
    Intel PCIe Storage
    2-way CrossFireX™
    ASUS SafeSlot

  • Realtek® S1200A
    Exclusive DTS Custom for
    GAMING Headsets TUF Gaming Audio Cover Audio Shielding
    Dedicated audio PCB layers
    Premium Japanese audio capacitors

  • ProCool Connector

  • 2 x RGB Strip Headers

  • Addressable Gen 2 RGB header

  • DDR4 2933 MHz
    ASUS OptiMem

  • Intel® Socket LGA1200

  • 32Gb/s M.2 x4 PCIe & SATA modeIntel® Optane Memory Ready

  • 1 x Front USB 3.2 Gen1 port

  • 1 x Front USB 3.2 Gen2 Type-C™port

  • 5 x SATA 3.0 ports

  • Intel® H470 Chipset

  • AURA Sync

  • 32Gb/s M.2 x4 PCIe mode Intel® Optane Memory Ready

  • 1 x Thunderbolt Header

ROCK-SOLID PERFORMANCE

With upgraded power delivery and comprehensive cooling options to fuel the latest Intel® CPUs, plus support for faster memory and storage, TUF GAMING H470-PRO (WI-FI) is the perfect foundation for your next high-core-count battle rig.

  • Power Design

  • Cooling

  • Memory & Storage

  • Connectivity

Power Design

  • SYSTEM STABILITY

  • CONTROLLER

EASY PC DIY

TUF Gaming motherboards are designed to be easy to set up and configure just the way you want —even for first-time builders. The TUF Gaming Alliance ecosystem makes selecting compatible parts easy, while Armoury Crate software offers full control of system settings via a single dashboard. TUF Gaming motherboards give you everything you need to build your dream gaming rig without adding complexity.

  • TUF Gaming Alliance

  • TUF Protection

  • Easy Configuration



Build with confidenceasus s1200 atx tuf gaming h470-pro wi-fi ddr4 motherboard

TUF Gaming Alliance is a collaboration between ASUS and trusted PC-component brands to ensure compatibility with a wide range of parts, such as PC cases, power supplies, CPU coolers, memory kits and more. With more partnerships and components being added regularly, the TUF Gaming Alliance will continue to grow even stronger. Learn More

IMMERSIVE GAMING

TUF GAMING H470-PRO (WI-FI) provides a complete, high-performance gaming package with a long list of features to improve your experience, including ultrafast networking for smoother online gameplay, pristine audio with positional cues for FPS gaming, and onboard RGB lighting that syncs with attached accessories to help you create a personalized gaming atmosphere.

  • Networking

  • Gaming Audio

  • Aura Sync RGB Lighting

Intel® WiFi 6 AX201

The Intel® WiFi 6 AX201 module is compatible with the 802.11ax standard and pushes theoretical peak bandwidth up to an incredible 2.4 Gbps. Perhaps more importantly for power users, it's optimized for more efficient operation on crowded networks with a lot of competing traffic. Pair your motherboard with ASUS WiFi 6 routers to fully experience the networking potential of WiFi 6. Learn more



*Actual speed varies, and depends on networking conditions.



asus s1200 atx tuf gaming h470-pro wi-fi ddr4 motherboard

asus s1200 atx tuf gaming h470-pro wi-fi ddr4 motherboard



INTEL® ETHERNET

Intel Ethernet Connection I219-V reduces CPU overhead and offers exceptionally high TCP and UDP throughput for faster, smoother data transfer.

Turbo LAN

NETWORK-OPTIMIZATION SOFTWARE FOR CUSTOMIZABLE PACKET PRIORITIZATION

Turbo LAN with cFosSpeed traffic-shaping technology allows you to configure application priority via an intuitive interface, and reduces network lag.



  • 1. One Click Turbo
    Adjust the network transmission priority by one click!

  • 2. Auto Detect Game List
    Turbo Lan will detect every game in system, and add in list automatically.

  • CPU

    Build in Intel® Socket 1200 for 10th Gen Intel® Core, Pentium® Gold and Celeron® Processors
    Supports Intel® 14 nm CPU
    Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
    * Refer to www.asus.com for CPU support list
    **Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.

  • Chipset

    Build in Intel® H470

  • Memory

    4 x DIMM, Max. 128GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
    Dual Channel Memory Architecture
    Supports Intel® Extreme Memory Profile (XMP)
    OptiMem
    * 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133 natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
    * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).

  • Graphic

    Integrated Graphics Processor
    1 x DisplayPort 1.4 **
    1 x HDMI 1.4b
    *Graphics specifications may vary between CPU types.
    **Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update.

  • Multi-GPU Support

    Supports AMD 2-Way CrossFireX Technology

  • Expansion Slots

    Intel® 10th Gen Processors
    1 x PCIe 3.0 x16 (x16 mode)
    Intel® H470 Chipset
    1 x PCIe 3.0 x16 (x4 mode)
    3 x PCIe x1

  • Storage

    Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
    Intel® H470 Chipset :
    1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*1
    1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
    5 x SATA 6Gb/s port(s)
    Support Raid 0, 1, 5, 10
    Intel® Rapid Storage Technology supports
    Intel® Optane™ Memory Ready

  • LAN

    Intel® I219-V 1Gb Ethernet
    TUF LANGuard

  • Wireless Data Network

    Intel® Wi-Fi 6 AX201
    2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO
    Supports up to 2.4Gbps max data rate
    Supports dual band frequency 2.4/5 GHz
    Supports channel bandwidth: HT20/HT40/HT80/HT160
    Supports CNVI interface

  • Audio

    Realtek® ALC S1200A 7.1 Surround Sound High Definition Audio CODEC
    - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
    Audio Feature :
    - Optical S/PDIF out port(s) at back panel
    - Audio cover
    - Audio Shielding
    - Dedicated audio PCB layers
    - Premium Japanese audio capacitors
    * Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.

  • USB Ports

    Rear USB Port ( Total 6 )
    2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C®)
    2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
    2 x USB 2.0 port(s)
    Front USB Port ( Total 6 )
    1 x USB 3.2 Gen 2 front panel connector port(s)(1 x USB Type-C®)
    1 x USB 3.2 Gen 1 port(s)(2 x Type-A)
    1 x USB 2.0 port(s)(2 x Type-A)
    1 x USB 2.0 port(s)(1 x Type-A)

  • Software Features

    ASUS Exclusive Software
    Armoury Crate
    - Aura Sync
    AI Suite 3:
    - Performance And Power Saving Utility
    Turbo V Evo
    EPU
    Digi+ VRM
    Fan Xpert 4
    System information
    - EZ update
    AI Charger
    ASUS Turbo LAN
    DTS Custom for GAMING Headsets
    WinRAR
    UEFI BIOS
    ASUS EZ DIY
    - ASUS CrashFree BIOS 3
    - ASUS EZ Flash 3
    - ASUS UEFI BIOS EZ Mode

  • ASUS Special Features

    ASUS TUF PROTECTION
    - ASUS DIGI+ VRM
    - ASUS Enhanced DRAM Overcurrent Protection
    - ASUS ESD Guards
    - TUF LANGuard
    - ASUS Overvoltage Protection
    - ASUS SafeSlot
    ASUS Q-Design
    - ASUS Q-DIMM
    - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
    - ASUS Q-Slot
    ASUS Thermal Solution
    - Stylish heatsink
    ASUS EZ DIY
    - Procool
    - Pre-mounted I/O shield
    AURA Sync
    - Standard RGB headers
    - Addressable Gen 2 RGB header

  • Back I/O Ports

    1 x PS/2 keyboard/mouse combo port(s)
    1 x DisplayPort
    1 x HDMI
    1 x LAN (RJ45) port(s)
    2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®)
    2 x USB 3.2 Gen 1 (blue) Type-A
    2 x USB 2.0
    1 x Optical S/PDIF out
    5 x Audio jack(s)

  • Internal I/O Ports

    1 x CPU Fan connector(s)
    1 x CPU OPT Fan connector(s)
    3 x Chassis Fan connector(s)
    1 x AIO_PUMP connector
    2 x Aura RGB Strip Headers
    1 x Addressable Gen 2 header(s)
    1 x USB 3.2 Gen2 connector support additional 1 USB ports(20-pin, Type-C)
    1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.2 Gen 1 port(s)
    1 x USB 2.0 connector(s) support(s) additional 1 USB 2.0 port(s)
    2 x M.2 Socket 3
    5 x SATA 6Gb/s connector(s)
    1 x Thunderbolt header(s)
    1 x 24-pin EATX Power connector(s)
    1 x 8-pin ATX 12V Power connector(s)
    1 x Front panel audio connector(s) (AAFP)
    1 x System panel(s) (Chassis intrusion header is inbuilt)
    1 x Clear CMOS jumper(s)
    1 x COM port header
    1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)

  • Accessories

    User's manual
    2 x SATA 6Gb/s cable(s)
    1 x M.2 Screw Package
    1 x Supporting DVD
    1 x TUF GAMING Sticker
    1 x TUF Certification card(s)
    1 x Wi-Fi moving antenna

  • BIOS

    192 (128+64) Mb Flash ROM, UEFI AMI BIOS

  • Manageability

    WOL by PME, PXE

  • Operating System

    Windows® 10 64-bit

  • Form Factor

    ATX Form Factor
    12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
