Regional Availability

Global, China, NA, EMEA, APJ, LATAM

Platform

Boxed Processor

Product Family

AMD Ryzen™ Processors

Product Line

AMD Ryzen™ 5 5000 G-Series Desktop Processors with Radeon™ Graphics

# of CPU Cores

6

# of Threads

12

Max. Boost Clock

Up to 4.6GHz

Base Clock

3.6GHz

L1 Cache

384KB

L2 Cache

3MB

L3 Cache

16MB

Default TDP

65W

AMD Configurable TDP (cTDP)

45-65W

Processor Technology for CPU Cores

TSMC 7nm FinFET

Unlocked for OverclockingAMD`s product warranty does not cover damages caused by overclocking, even when overclocking is enabled via AMD hardware and/or software. GD-26.

Yes

CPU Socket

AM4

Thermal Solution (PIB)

AMD Wraith Stealth

Thermal Solution (MPK)

AMD Wraith Stealth

Max. Operating Temperature (Tjmax)

95°C

Launch Date

1/8/2024

*OS Support

Windows 11 - 64-Bit Edition

Windows 10 - 64-Bit Edition

RHEL x86 64-Bit

Ubuntu x86 64-Bit

*Operating System (OS) support will vary by manufacturer.

PCI Express® Version

PCIe® 3.0

System Memory Type

DDR4

Memory Channels

2

System Memory Specification

Up to 3200MT/s

Max Memory Speed

2x1R

DDR4-3200

2x2R

DDR4-3200

4x1R

DDR4-2933

4x2R

DDR4-2667

Graphics Model

Radeon™ Graphics

Graphics Core Count

7

Graphics Frequency

1900 MHz

Product ID Boxed

100-100001488BOX

Product ID Tray

100-000001488

Product ID MPK

100-100001488MPK
