Display

• Diagonal Size85"
•
• Panel TypeVA
•
• Resolution3,840 x 2,160
•
• Pixel Pitch (HxV)0.4875 (H) x 0.4875(W) mm
•
• Brightness (Typ)300 nit
•
• Contrast Ratio54,000:1
•
• Viewing Angle (H/V)178/178
•
• Response Time8ms
•
• Color Gamut72%
•
• Glass Haze2%
•
• H-Scanning Frequency15 ~ 135kHz
•
• Maximum Pixel Frequency594MHz
•
• V-Scanning Frequency24 ~ 75Hz
•
• Contrast Ratio (Dynamic)Mega
•
• Operation Time Support16/7

Connectivity

• HDMI In2
•
• Version of HDMI2.0
•
• Version of DPNo
•
• Version of HDCP2.2
•
• USB1
•
• Audio OutStereo Mini Jack
•
• RS232 InStereo Mini Jack
•
• RJ45 InYes
•
• 3G DongleNo

Electrical

• Power SupplyAC100-240V 50/60Hz
•
• Power Consumption (On Mode)273 W
•
• Power Consumption (Sleep Mode)0.5 W

Set Dimension (WxHxD)

• Set Dimension (WxHxD)1900.9 x 1086.2 x 26.9 mm
•
• Package Dimension (HxWxD)2075 x 1237 x 220 mm

Weight

• Net Weight41.5 kg
•
• Package Weight54.3 kg

Operation Conditions

• Temperature0?~ 40?
•
• Humidity10 ~ 80%, non-condensing

Mechanical Specification

• VESA Mount600 x 400 mm
•
• Bezel Width3 Bezel-less
•
• Frame MaterialGlossy

Optional Feature

• MountWMN8200SG

SoC

• OS VersionTizen 4.0
•
• Flash Memory Size8GB

Certification and Compliance

• EMCClass B
•
• Safety
