Display

• Diagonal Size74.5"
• Panel TypeVA
• Resolution4K (3840 x 2160)
• Pixel Pitch (HxV)0.430 x 0.430 mm
• Brightness (Typ)450(w/o glass)
• Contrast Ratio54,000:1(without Glass)
• Viewing Angle (H/V)178 / 178
• Response Time8 (GTG)
• Color Gamut (NTSC Coverage)72 %
• Glass Haze2%(without glass)
• H-Scanning Frequency30 - 81 kHz
• Maximum Pixel Frequency148.5 MHz
• V-Scanning Frequency48 - 75 Hz
• Operation Time Support12/7

Connectivity

• HDMI In2
• Version of HDMI2.0
• Version of HDCP2.2
• USB2 (Front 1, Rear 1)
• Audio OutStereo Mini Jack
• Video OutYes
• RS232 InYes
• RJ45 InYes
• WiFiYes
• BluetoothYes

Power

• Power SupplyAC 220 - 240 V (50/60 Hz)
• Power Consumption (On Mode)385 W

Dimension

• Set Dimension (WxHxD)1735.4 x 1038.5 x 83.7 mm
• Package Dimension (HxWxD)1885 x 1171 x 210 mm

Weight

• Net Weight53.6 kg
• Package Weight64.5 kg

Operation Conditions

• Temperature0 ~ 40 ?
• Humidity10 ~ 80 (Non-Condensing)

Mechanical Specification

• VESA Mount400 x 400 mm
• Bezel Width23.5
• Bezel ColourGrey White
• Frame MaterialNon-Glossy(Plastic)

Optional Feature

• TouchYes
• MountYes

SoC

• OS VersionTizen 9.0
• Flash Memory Size64GB

Touch

• Touch TechnologyIR

Certification and Compliance

• EMCClass A FCC (USA) Part 15, Subpart B KCC/EK (Korea) Tuner : KN32 / KN35 Tunerless : KN32 / KN35 CE (Europe) EN55032 : 2012 or 2015 EN55024:2010 or EN 55035:2017 VCCI (Japan) VCCI CISPR32:2016 CCC(China) GB/T9254-2008 GB17625.1-2012 BSMI (Taiwan) CNS13438 ( ITE EMI ) CNS14336-1 ( ITE Safety ) CNS15663 (RoHS) C-Tick (Australia) AS/NZS CISPR32:2015 GOST(Russia/CIS) ROCT CISPR 24-2013 ROCT CISPR 22:2005
• SafetyCB (Europe) : IEC60950-1/EN60950-1CCC (China) : GB4943.1-2011PSB (Singapore ) : PSB+IEC60950-1NOM (Mexico ) : NOM-001-SCFI-1993IRAM (Argentina ) : IRAM+IEC60950-1SASO (Saudi Arabia ) : SASO+IEC60950-1BIS(India) : IEC60950-1 / IS13252NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998KC(Korea) : K 60950-1EAC(Russia) : EAC+IEC60950-1INMETRO(Brazil) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(Australia) : IEC60950-1/AS/NZS 60950-1UL(USA) : cUL60950
