Display

• Diagonal Size65"
•
• Panel TypeVA
•
• Resolution3,840 x 2,160
•
• Pixel Pitch (HxV)0.372 x 0.372(mm)
•
• Brightness (Typ)350cd/m2 (w/o glass), 220cd/m2 (w/glass)
•
• Contrast Ratio54000:1(without glass)
•
• Viewing Angle (H/V)178/178
•
• Response Time8ms
•
• Color Gamut72%
•
• Glass Haze2%(without glass)
•
• H-Scanning Frequency30~81 khz
•
• Maximum Pixel Frequency594Mhz
•
• V-Scanning Frequency48~75 Khz
•
• Dynamic Contrast RatioN/A
•
• Operation Time Support16/7

Connectivity

• HDMI In2
•
• DP In1
•
• DVI InN/A
•
• Version of HDMI2
•
• Version of DP1.2
•
• Version of HDCP2.2
•
• Tuner InN/A
•
• USB1(Rear), 3 (with optional front tray, Internal 1, External 1, USB-C 1)
•
• IR InN/A
•
• HDBaseT InN/A
•
• Audio InN/A
•
• Audio OutStereo Mini Jack
•
• Video OutN/A
•
• Power OutN/A
•
• RS232 InYes
•
• RS232 OutN/A
•
• RJ45 InYes
•
• RJ45 OutN/A
•
• WiFiYes
•
• 3G DongleN/A
•
• BluetoothYes

Electrical

• Power SupplyAC100-240V 50/60Hz
•
• Power Consumption (Off Mode)N/A
•
• Power Consumption (On Mode)192.5W
•
• Power Consumption (Sleep Mode)0.5W

Set Dimension (WxHxD)

• Set Dimension (WxHxD)1522.4 x 897.6 x 62.9 mm
•
• Package Dimension (HxWxD)1691 x 1055 x 198 mm

Weight

• Net Weight39.7 kg
•
• Package Weight48.2 kg

Operation Conditions

• Temperature0?~40?
•
• Humidity10 ~ 80%, non-condensing

Mechanical Specification

• VESA Mount400 x 400 mm
•
• Bezel Width26.2
•
• Frame MaterialPlastic

Optional Feature

• TouchYes
•
• MountYes(Model Name : WMN-WM65R)
•
• StandN/A

SoC

• OS VersionTizen 6.5
•
• Flash Memory Size32GB

Eco

• Energy Efficiency ClassN/A

Touch

• Touch TechnologyIR

Certification and Compliance

• EMCClass A FCC (USA) Part 15, Subpart B KCC/EK (Korea) Tuner : KN32 / KN35 Tunerless : KN32 / KN35 CE (Europe) EN55032 : 2012 or 2015 EN55024:2010 or EN 55035:2017 VCCI (Japan) VCCI CISPR32:2016 CCC(China) GB/T9254-2008 GB17625.1-2012 BSMI (Taiwan) CNS13438 ( ITE EMI ) CNS14336-1 ( ITE Safety ) CNS15663 (RoHS) C-Tick (Australia) AS/NZS CISPR32:2015 GOST(Russia/CIS) ROCT CISPR 24-2013 ROCT CISPR 22:2005
•
• SafetyCB (Europe) : IEC60950-1/EN60950-1CCC (China) : GB4943.1-2011PSB (Singapore ) : PSB+IEC60950-1NOM (Mexico ) : NOM-001-SCFI-1993IRAM (Argentina ) : IRAM+IEC60950-1SASO (Saudi Arabia ) : SASO+IEC60950-1BIS(India) : IEC60950-1 / IS13252NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998KC(Korea) : K 60950-1EAC(Russia) : EAC+IEC60950-1INMETRO(Brazil) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(Australia) : IEC60950-1/AS/NZS 60950-1UL(USA) : cUL60950
