Display

• Diagonal Size 55"
• Panel Type Direct LED BLU
• Resolution 3,840 x 2,160
• Pixel Pitch (HxV) 0.315(H)x 0.315(V) mm
• Brightness (Typical) 300
• Contrast Ratio5 4,000:1
• Viewing Angle (H/V) 89
• Response Time 6.5ms
• Color Gamut 72%
• Glass Haze 2%
• H-Scanning Frequency 30 ~ 81KHz
• Maximum Pixel Frequency 594MHz
• V-Scanning Frequency 48 ~ 75hz
• Dynamic Contrast Ratio Mega DCR

Connectivity

• HDMI In 2
• DP In N/A
• DVI In N/A
• Tuner In N/A
• USB 1
• Component In N/A
• Composite In N/A
• RGB In N/A
• IR In N/A
• HDBaseT In N/A
• Audio In N/A
• Audio Out Stereo Mini Jack
• Video Out N/A
• Power Out N/A
• RS232 In Stereo Mini Jack
• RS232 Out N/A
• RJ45 In Yes
• RJ45 Out N/A
• WiFi N/A
• 3G Dongle No
• Bluetooth N/A

Electrical

• Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
• Power Consumption (Off Mode) N/A
• Power Consumption (On Mode) 154
• Power Consumption (Sleep Mode) 0.5 W

Set Dimension (WxHxD)

• Set Dimension (WxHxD) 1230.5 x 707.2 x 59.9 mm
• Package Dimension (HxWxD) 1386 x 843 x 158 mm

Weight

• Net Weight 14.1 kg
• Package Weight 19.3 kg

Operation Conditions

• Temperature 0?~ 40?
• Humidity 10 ~ 80%, non-condensing

Mechanical Specification

• VESA Mount 200 x 200 mm
• Bezel Width 3 Bezel-less
• Frame Material Glossy

General Feature

• External Memory Slot N/A

Optional Feature

• Mount WMN4070SE
• Stand STN-L4355F

Internal Player (MagicInfo)

• MagicInfo Daisychain Videowall Support No

Eco

• Energy Efficiency Class N/A

Certification and Compliance

• EMC CLASS B FCC (USA) PART 15, SUBPART B KCC/EK (KOREA) TUNER : KN32 / KN35 TUNERLESS : KN32 / KN35 CE (EUROPE) EN55032 : 2012 OR 2015 EN55024:2010 OR EN 55035:2017 VCCI (JAPAN) VCCI CISPR32:2016 CCC(CHINA) GB/T9254-2008 GB17625.1-2012 BSMI (Taiwan) CNS13438 ( ITE EMI ) CNS14336-1 ( ITE SAFETY ) CNS15663 (ROHS) C-TICK (AUSTRALIA) AS/NZS CISPR32:2015 GOST(RUSSIA/CIS) ROCT CISPR 24-2013 ROCT CISPR 22:2005
• Safety CB (EUROPE) : IEC60950-1/EN60950-1CCC (CHINA) : GB4943.1-2011PSB (SINGAPORE ) : PSB+IEC60950-1NOM (MEXICO ) : NOM-001-SCFI-1993IRAM (ARGENTINA ) : IRAM+IEC60950-1SASO (SAUDI ARABIA ) : SASO+IEC60950-1BIS(INDIA) : IEC60950-1 / IS13252NOM(MEXICO) : TUNER : NOM-001-SCFI-1993 TUNERLESS : NOM-019-SCFI-1998KC(KOREA) : K 60950-1EAC(RUSSIA) : EAC+IEC60950-1INMETRO(BRAZIL) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(AUSTRALIA) : IEC60950-1/AS/NZS 60950-1UL(USA) : CUL60950
