Display

• Diagonal Size50"
•
• Panel TypeDirect LED BLU
•
• Resolution3,840 x 2,160
•
• Pixel Pitch (HxV)0.285375 (H) × 0.285375 (V) mm
•
• Brightness (Typical)300
•
• Contrast Ratio54,000:1
•
• Viewing Angle (H/V)178/178
•
• Response Time8ms
•
• Color Gamut72%
•
• Glass Haze2%
•
• H-Scanning Frequency30 ~ 81KHz
•
• Maximum Pixel Frequency594MHz
•
• V-Scanning Frequency48 ~ 75hz
•
• Dynamic Contrast RatioMega DCR

Connectivity

• HDMI In2
•
• DP InN/A
•
• DVI InN/A
•
• Tuner InN/A
•
• USB1
•
• Component InN/A
•
• Composite InN/A
•
• RGB InN/A
•
• IR InN/A
•
• HDBaseT InN/A
•
• Audio InN/A
•
• Audio OutStereo Mini Jack
•
• Video OutN/A
•
• Power OutN/A
•
• RS232 InStereo Mini Jack
•
• RS232 OutN/A
•
• RJ45 InYes
•
• RJ45 OutN/A
•
• WiFiN/A
•
• 3G DongleNo
•
• BluetoothN/A

Electrical

• Power SupplyAC 100 - 240 V~ (+/- 10 %), 50/60 Hz
•
• Power Consumption (Off Mode)N/A
•
• Power Consumption (On Mode)149
•
• Power Consumption (Sleep Mode)0.5 W

Set Dimension (WxHxD)

• Set Dimension (WxHxD)1116.8 x 644.2 x 59.9 mm
•
• Package Dimension (HxWxD)1264 x 780 x 150 mm

Weight

• Net Weight11.7 kg
•
• Package Weight16.1 kg

Operation Conditions

• Temperature0?~ 40?
•
• Humidity10 ~ 80%, non-condensing

Mechanical Specification

• VESA Mount200 x 200 mm
•
• Bezel Width3 Bezel-less
•
• Frame MaterialGlossy

General Feature

• External Memory SlotN/A

Optional Feature

• MountWMN4070SE
•
• StandSTN-L4355F

Internal Player (MagicInfo)

• MagicInfo Daisychain Videowall SupportNo

Eco

• Energy Efficiency ClassN/A

Certification and Compliance

• EMCCLASS B FCC (USA) PART 15, SUBPART B KCC/EK (KOREA) TUNER : KN32 / KN35 TUNERLESS : KN32 / KN35 CE (EUROPE) EN55032 : 2012 OR 2015 EN55024:2010 OR EN 55035:2017 VCCI (JAPAN) VCCI CISPR32:2016 CCC(CHINA) GB/T9254-2008 GB17625.1-2012 BSMI (Taiwan) CNS13438 ( ITE EMI ) CNS14336-1 ( ITE SAFETY ) CNS15663 (ROHS) C-TICK (AUSTRALIA) AS/NZS CISPR32:2015 GOST(RUSSIA/CIS) ROCT CISPR 24-2013 ROCT CISPR 22:2005
•
• SafetyCB (EUROPE) : IEC60950-1/EN60950-1CCC (CHINA) : GB4943.1-2011PSB (SINGAPORE ) : PSB+IEC60950-1NOM (MEXICO ) : NOM-001-SCFI-1993IRAM (ARGENTINA ) : IRAM+IEC60950-1SASO (SAUDI ARABIA ) : SASO+IEC60950-1BIS(INDIA) : IEC60950-1 / IS13252NOM(MEXICO) : TUNER : NOM-001-SCFI-1993 TUNERLESS : NOM-019-SCFI-1998KC(KOREA) : K 60950-1EAC(RUSSIA) : EAC+IEC60950-1INMETRO(BRAZIL) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(AUSTRALIA) : IEC60950-1/AS/NZS 60950-1UL(USA) : CUL60950
