Picture/Display

Panel Size

48.8 inch / 124 cm

Aspect ratio

32:9

LCD panel type

VA LCD

Backlight type

W-LED system

Pixel pitch

0.2328 x 0.2328 mm

Brightness

450 (SDR) cd/m², 500 (HDR)  cd/m²

Display colors

1.07B

Color gamut (typical)

NTSC 97%, sRGB 119%*

Contrast ratio (typical)

3000:1

SmartContrast

80,000,000:1

Response time (typical)

4 ms (Gray to Gray)*

Viewing angle

• 178º (H) / 178º (V)

• @ C/R > 10

Picture enhancement

SmartImage

Maximum resolution

5120x1440@75Hz (HDMI/DP/USB-C)*

Effective viewing area

1191.936(H)x335.232(V)mm, 1800R curvature*

Scanning Frequency

HDMI: 30 - 140 kHz (H) / 48-75 Hz (V); DP: 30 - 114 kHz (H) / 48-75 Hz (V); USB-C: 30 - 114 kHz (H) / 30-75 Hz (V)

sRGB

Yes

Delta E

< 2

SoftBlue

Yes

Flicker-free

Yes

Pixel Density

109 PPI

Display Screen Coating

Anti-Glare, 3H, Haze 25%

SmartUniformity

93 ~ 105%

EasyRead

Yes

Adaptive sync (VRR)

Yes

HDR

DisplayHDR 400 certified

EyeSafe

Yes

Connectivity

Signal Input

HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD)

Sync Input

• Separate Sync

• Sync on Green

Audio (In/Out)

Audio out

RJ45

Ethernet LAN up to 1G

HDCP

HDCP 1.4 (HDMI / DisplayPort / USB-C), HDCP 2.2 (HDMI / DisplayPort / USB-C)

HBR3

HBR3

USB Hub

USB 3.2 Gen 1 / 5 Gbps, USB-B upstream x 1, USB-A downstream x 2 (with 1 for fast charge B.C 1.2), USB-C downstream x 1 (Data, PD 15W)

Power Delivery

Max power delivery

up to 100W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A, 20V/4.8A)*

Version

USB PD version 3.0

Convenience

Built-in Speakers

3 W x 2

Plug & Play Compatibility

• DDC/CI

• Mac OS

• sRGB

• Windows 11 / 10 / 8.1 / 8

User convenience

• SmartImage

• Input

• User

• Menu

• Power On/Off

OSD Languages

• Brazil Portuguese

• Czech

• Dutch

• English

• French

• Finnish

• German

• Greek

• Hungarian

• Italian

• Japanese

• Korean

• Portuguese

• Polish

• Russian

• Simplified Chinese

• Spanish

• Swedish

• Traditional Chinese

• Turkish

• Ukrainian

Other convenience

• Kensington lock

• Earphone hook

• VESA mount (100x100mm)

Control software

SmartControl

MultiView

• PIP/PBP mode

• 2x devices

KVM

Yes (USB-C/USB-B)

Stand

Height adjustment

150  mm

Swivel

-/+30  degree

Tilt

-5/15  degree

Power

ECO mode

34.18 W (typ.)

Power supply

• Built-in

• 100-240VAC, 50-60Hz

Off mode

0.3 W (typ.)

On mode

52.27 W (typ.) (EnergyStar test method)

Standby mode

0.3 W (typ.)

Power LED indicator

• Operation - White

• Standby mode- White (blinking)

Dimensions

Packaging in mm (WxHxD)

1290 x 475 x 300  mm

Product without stand (mm)

1193 x 373 x 164  mm

Product with stand(max height)

1193 x 583 x 268  mm

Weight

Product with packaging (kg)

22.70  kg

Product with stand (kg)

15.30  kg

Product without stand (kg)

11.67  kg

Operating conditions

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

Temperature range (operation)

0°C to 40  °C

Relative humidity

20%-80  %

Temperature range (storage)

-20°C to 60  °C

MTBF (demonstrated)

70,000 hrs (excluded backlight)

Sustainability

Environmental and energy

• PowerSensor

• LightSensor

• EnergyStar 8.0

• EPEAT*

• RoHS

Post consumer recycled plastic

85%+OBP 5%

Recyclable packaging material

100  %

Specific Substances

• Mercury free

• PVC / BFR free housing

Compliance and standards

Regulatory Approvals

• CB

• CE Mark

• ETL

• CEC

• TUV/GS

• TUV Ergo

• TCO Certified

• TCO Certified Edge

• EAC

• EAC ROHS

• MEPS

• UKCA

• EMF

• FCC

• ICES-003

• TÜV Rheinland Low Blue Light (Hardware Solution)

• eyesafe® CERTIFIED 2.0

Cabinet

Finish

Texture

Foot

Silver

Front bezel

Charcoal

Rear cover

Charcoal
