Display Input: HDMI In
Display Output: HDMI Out
| Video Input | |
| Interfaces | 1 x HDMI Type A Female (Black) |
| Impedance | 100 Ω |
| Max. Distance | 3m at 3840x2160 @ 60Hz (4:4:4) |
| Video Output | |
| Interfaces | 4 x HDMI Type A Female (Black) |
| Impedance | 100 Ω |
| Max. Distance | 3m at 3840x2160 @ 60Hz (4:4:4) |
| Video | |
| Max. Data Rate | 18 Gbps (6 Gbps Per Lane) |
| Max. Pixel Clock | 600 MHz |
| Compliance | HDMI (3D, Deep Color, 4K) HDCP 2.2 Compatible |
| Max. Resolution | 3840 x 2160 @ 60Hz (4:4:4) |
| Audio | |
| Input | 1 x HDMI Type A Female (Black) |
| Output | 4 x HDMI Type A Female (Black) |
| Connectors | |
| Power | 1 x USB-C (5V/1A) |
| Cable Length | |
| USB Cable | 1 x USB Type-C to Type-A (1m) |
| LEDs | |
| LED Indicator | 4 x Port Indicator (Orange) |
| Power | 2 (Orange, Bottom Side) |
| Environmental | |
| Operating Temperature | 0-40 °C |
| Storage Temperature | -20 - 60 °C |
| Humidity | 0 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | PC |
| Weight | 0.10 kg ( 0.22 lb ) |
| Dimensions (L x W x H) | 14.50 x 5.65 x 1.52 cm (5.71 x 2.22 x 0.6 in.) |
| Carton Lot | 20 pcs |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
