LAN Speed: 25 Gigabit
Ports: 32 Port
Switch Tech: Managed
| Overview | |
|---|---|
| Dimensions | 442.4 x 43.7 x 480 mm (17.4 x 1.7 x 18.9") |
| Port Layout | 25G SFP28 – 32 (25G/10G/1G) |
| Redundancy | DC Power Backup |
| Layer 3 | Y |
| Form Factor | Rack Mount (1U) |
| Etherlighting™ | Y |
| Performance | |
| Switching Capacity | 1.6 Tbps |
| Total Non-Blocking Throughput | 800 Gbps |
| Forwarding Rate | 1.2 Bpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 32,000 |
| L3 Table Size | |
| ARP Entries | 128,000 |
| IPv4 Routes | 256,000 |
| IPv4 Static Routes | 512 |
| Packet Buffer Size | 8 MB |
| Access Lists – IPv4 | 256 |
| Access Lists – MAC | 256 |
| Layer 3 Features | |
| DHCP Server (Local Networks) | Y |
| DHCP Relay | Y |
| Inter-VLAN Routing (Local Networks) | Y |
| Static Routing (Local Networks) | Y |
| Layer 2 Features | |
| LACP Port Aggregation | Y |
| STP & RSTP | Y |
| Advanced IGMP Configuration (Querier, Fast Leave, Router Port) | Y |
| IGMP Snooping | Y |
| 802.1X Control | Y |
| MAC-Based ACLs & Device Isolation | Y |
| DHCP Snooping & Guarding | Y |
| Egress Rate Limit | Y |
| Flow Control | Y |
| Storm Control | Y |
| Multicast & Broadcast Rate Limiting | Y |
| MAC Address Blocking | Y |
| IP-Based ACLs & Network Isolation | Y |
| MAC-Based Port Restriction | Y |
| Port Isolation | Y |
| Port Mirroring | Y |
| Jumbo Frames | Y |
| LLDP-MED | Y |
| Voice VLAN | Y |
| Loop Protection | Y |
| Virtual Network Override | Y |
| Hardware | |
| Max. Power Consumption | 200W |
| Power Method | (1) Universal input, 100–240V AC, 50/60 Hz (1) USP RPS DC input |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 200W |
| Supported Voltage Range | 100–240V AC |
| Management | Ethernet AR |
| Heat Dissipation | 457 BTU/hr |
| Weight | Without mounting bracket: 7.1 kg (15.7 lbs) With mounting bracket: 7.2 kg (15.9 lbs) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Supported Rack Depth | 482.6 mm (19") four-post racks Posts depths ranging from 600 to 1,066 mm (23.6–42") |
| LCM Display | 1.3" touchscreen |
| ESD Protection | Air: ±12kV, contact: ±8kV |
| Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Etherlighting™ SFP28 | Y |
| LEDs – RPS | Y |
| NDAA Compliant | Y |
| Certifications | CE, FCC, IC, Anatel: 05977-25-08356 |
