General Feature

• ApplicationClient PCs, Game Consoles
•
• Capacity2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
•
• Form FactorM.2 (2280)
•
• InterfacePCIe Gen 4.0 x4, NVMe 2.0
•
• Dimension (Pack: WxHxD)80 x 24.3 x 8.2 mm (with heatsink)
•
• WeightMax 28.0g Weight
•
• Storage MemorySamsung V-NAND 3-bit MLC
•
• ControllerSamsung in-house Controller
•
• Cache MemorySamsung 2GB Low Power DDR4 SDRAM

Special Feature

• TRIM SupportSupported
•
• S.M.A.R.T SupportSupported
•
• GC (Garbage Collection)Auto Garbage Collection Algorithm
•
• Encryption SupportAES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
•
• WWN SupportNot supported
•
• Device Sleep Mode SupportYes

Performance

• Sequential ReadUp to 7,450 MB/s * Performance may vary based on system hardware & configuration
•
• Sequential WriteUp to 6,900 MB/s * Performance may vary based on system hardware & configuration
•
• Random Read (4KB, QD32)Up to 1,400,000 IOPS * Performance may vary based on system hardware & configuration
•
• Random Write (4KB, QD32)Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration
•
• Random Read (4KB, QD1)Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
•
• Random Write (4KB, QD1)Up to 80,000 IOPS * Performance may vary based on system hardware & configuration

Environment

• Average Power Consumption (system level)*Average: 5.5 W*Maximum: 8.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
•
• Power consumption (Idle)Max. 55 mW * Actual power consumption may vary depending on system hardware & configuration
•
• Allowable Voltage3.3 V ± 5 % Allowable voltage
•
• Reliability (MTBF)1.5 Million Hours Reliability (MTBF)
•
• Operating Temperature0 - 70 ? Operating Temperature
•
• Shock1,500 G & 0.5 ms (Half sine)

Accessories

• Installation KitNot Available

Software

• Management SWMagician Software for SSD management

Warranty

• 5-Year Limited Warrantyor 1200 TBW Limited Warranty
