| Specifications |
24 TB |
| Standard Model Number |
ST24000NT002 |
| Interface |
SATA 6Gb/s |
| Features |
|
| Drive Bays Supported |
Unlimited |
| Recording Technology |
CMR |
| Drive Design (Air or Helium) |
Helium |
| Workload Rate Limit (WRL) |
550 |
| Rotational Vibration (RV) Sensors |
Yes |
| Cache (MB) |
512 MB |
| Reliability/Data Integrity |
|
| Mean Time Between Failures (MTBF, hours) |
2500000 hr |
| Non-recoverable Read Errors per Bits Read, Max |
1 per 10E15 |
| Power-On Hours (per year) |
8,760 |
| Sector Size (Bytes per Logical Sector) |
512E |
| Rescue Data Recovery Services (years)3 |
3 |
| Limited Warranty (years) |
5 |
| Performance |
|
| Spindle Speed (RPM) |
7200RPM |
| Interface Access Speed (Gb/s) |
6.0, 3.0, 1.5 |
| Max. Sustained Transfer Rate OD (MB/s) |
285 |
| Rotational Vibration @ 10-1500 Hz (rad/s) |
12.5 |
| Power Consumption |
|
| Startup Current, Typical (12V, A) |
2.0 A |
| Idle Power, Average (W) |
6.3 W |
| Average Operating Power (W) |
7.8 W |
| Standby Mode, Typical (W) |
1.1 W |
| Sleep Mode, Typical (W) |
1.1 W |
| Power Supply Requirements |
+12 V and +5 V |
| Environmental/Temperature |
|
| Operating Temperature (ambient, min °C) |
5°C |
| Operating Temperature (drive reported, max °C)4 |
65°C |
| Non-operating Temperature (ambient, min °C) |
-40°C |
| Non-operating Temperature (ambient, max °C) |
70°C |
| Environmental/Acoustics |
|
| Vibration, Non-operating: 10 Hz to 500 Hz (Grms) |
2.27 |
| Acoustics, Idle (typical, measured in Idle 1 state) (dBA) |
20 |
| Acoustics, Seek (typical) (dBA) |
26 |
| Environmental/Shock |
|
| Shock, Operating 2 ms (Read/Write) (Gs) |
40/40 Gs |
| Shock, Non-operating, 1 ms and 2 ms (Gs) |
200 |
| Physical |
|
| Height (mm/in) |
26.11 mm/1.028 in |
| Width (mm/in, max) |
101.85 mm/4.01 in |
| Depth (mm/in, max) |
146.99 mm/5.787 in |
| Weight (g/lb, typical) |
685 g/1.512 lb |
| Carton Unit Quantity |
20 |
| Cartons per Pallet / Cartons per Layer |
40/8 |
