24 Port Ubiquiti USW-EnterpriseXG-24 L3 Switch

Web ID: 32812

The Switch Enterprise XG 24 (USW Enterprise XG 24) is a fully managed, mult-gigabit, Layer 3 switch with (24) 10GbE RJ45 ports and (2) 25G SFP28 ports. The USW Enterprise XG 24 also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.
Manufacturer Warranty: 1 Year
Manufacturer PN: USW-EnterpriseXG-24
GTIN: 810010072993

Dimensions442 x 44 x 285 mm (17.4 x 1.7 x 11.2")
WeightWithout Mount: 4.47 kg (9.85 lb)
With Mount: 4.57 kg (11.02 lb)
Enclosure MaterialsSGCC Steel
Mount MaterialSGCC Steel
Total Non-Blocking Throughput290 Gbps
Switching Capacity580 Gbps
Forwarding Rate431.52 Mpps
Max. Power Consumption100W
Power Method(1) Universal AC input: 100-240VAC, 2A Max., 50/60 Hz
(1) USP-RPS DC input: 11.5VDC, 8.7A
Power SupplyAC/DC, Internal, 100W
Management InterfaceEthernet In-Band
Networking Interfaces(24) 100/1,000/2,500/5,000/10,000 Mbps RJ45 Ethernet
SFP28 Interfaces(2) 1/10/25 Gbps SFP28*
*The two SFP28 ports don't support mixed speed at 25Gbps mode. Once one of the SFP28 ports is configured at 25Gbps mode, the others will be limited at 25Gbps too. The SFP28 ports only support mixed speed when all ports are at 1Gbps or 10Gbps.
ServicesSMB Layer 3 Gigabit Ethernet Switch
ESD/EMP ProtectionAir: ± 16 kV, Contact: ± 12 kV
LCM Display1.3" Touchscreen
Bootup Animation: Bootup in Progress
Firmware Upgrade Icon: Firmware Upgrading
Steady White: Factory Defaults, Awaiting Adoption
Steady Blue: Device is Adopted
ButtonFactory Reset
LEDsWhite: Link or Activity
Operating Temperature-5 to 40° C (23 to 104° F)
Operating Humidity10 - 95% Noncondensing
CertificationsCE, FCC, IC
