Picture/Display

LCD panel type

IPS technology

Backlight type

W-LED system

Panel Size

23.8 inch / 60.5 cm

Display Screen Coating

Anti-Glare, 3H, Haze 25%

Effective viewing area

527.04 (H) x 296.46 (V)

Aspect ratio

16:9

Maximum resolution

1920 x 1080 @ 75 Hz*

Pixel Density

93 PPI

Response time (typical)

4 ms (Gray to Gray)*

Brightness

250  cd/m²

Contrast ratio (typical)

1000:1

SmartContrast

50,000,000:1

Pixel pitch

0.2745 x 0.2745 mm

Viewing angle

• 178º (H) / 178º (V)

• @ C/R > 10

Flicker-free

Yes

Picture enhancement

SmartImage

Color gamut (typical)

NTSC 91%*, sRGB 107%*

Display colors

16.7M

Scanning Frequency

30 - 85 kHz (H) / 48 - 75 Hz (V)

sRGB

Yes

LowBlue Mode

Yes

EasyRead

Yes

Adaptive sync

Yes

Connectivity

Signal Input

DisplayPort 1.2 x 1, HDMI 1.4 x 1, USB-C 3.2 Gen 2 x 1 (upstream, power delivery up to 65 W)

HDCP

HDCP 1.4 (HDMI/DP/USB-C)

HBR3

Yes

Signal Output

DisplayPort out* (DP / USB-C)

USB:

USB 3.2 Gen 2 x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2)

Audio (In/Out)

• PC audio-in

• Headphone out

RJ45

Ethernet LAN up to 1G*, Wake On Lan

Sync Input

Separate Sync

USB

USB-C

Reversible plug connector

Super speed

Data and Video transfer

DP

Built-in Display Port Alt mode

Power delivery

USB PD version 3.0

USB-C max. power delivery

Up to 65 W (5V/3A; 9V/3A; 10V/3A; 12V/3A; 15V/3A; 20V/3.25A)

Convenience

Built-in Speakers

2 W x 2

User convenience

• SmartImage

• Input

• PowerSensor

• Menu

• Power On/Off

Control software

SmartControl

OSD Languages

• Brazil Portuguese

• Czech

• Dutch

• English

• Finnish

• French

• German

• Greek

• Hungarian

• Italian

• Japanese

• Korean

• Polish

• Portuguese

• Russian

• Simplified Chinese

• Spanish

• Swedish

• Traditional Chinese

• Turkish

• Ukranian

Other convenience

• Kensington lock

• VESA mount (100x100mm)

Plug & Play Compatibility

• DDC/CI

• Mac OS X

• sRGB

• Windows 10 / 8.1 / 8 / 7

Stand

Height adjustment

150  mm

Pivot

-/+ 90 degree

Swivel

-/+ 180  degree

Tilt

-5 ~ 35  degree

Power

ECO mode

14.6 W (typ.)

On mode

15.2 W (typ.) (EnergyStar test method)

Standby mode

< 0.5 W (typ.)

Off mode

Zero watts with Zero switch

Power LED indicator

• Operation - White

• Standby mode- White (blinking)

Power supply

• Built-in

• 100-240VAC, 50-60Hz

Dimensions

Product with stand(max height)

540 x 501 x 205  mm

Product without stand (mm)

540 x 323 x 51  mm

Packaging in mm (WxHxD)

600 x 465 x 198  mm

Weight

Product with stand (kg)

4.98  kg

Product without stand (kg)

3.40  kg

Product with packaging (kg)

7.04  kg

Operating conditions

Temperature range (operation)

0°C to 40°C  °C

Temperature range (storage)

-20°C to 60°C  °C

Relative humidity

20%-80  %

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

MTBF (demonstrated)

70,000 hrs (excluded backlight)

Sustainability

Environmental and energy

• PowerSensor

• LightSensor

• EnergyStar 8.0

• EPEAT*

• RoHS

• TCO Certified Edge

Recyclable packaging material

100  %

Post consumer recycled plastic

85%

Specific Substances

• PVC / BFR free housing

• Mercury free

Compliance and standards

Regulatory Approvals

• CE Mark

• FCC Class B

• SEMKO

• CU-EAC

• TUV/GS

• TUV Ergo

• EPA

• UKRAINIAN

• ICES-003

• CB

• TUV Eye Comfort certified

• MEPS

• RCM

Cabinet

Front bezel

Black

Rear cover

Black

Foot

Black

Finish

Texture
