PERFORMANCE
Processor	Intel® Core™ i5-14500, 14C (6P + 8E) / 20T, P-core 2.6 / 5.0GHz, E-core 1.9 / 3.7GHz, 24MB
Graphics	Integrated Intel® UHD Graphics 770
Chipset	Intel® Q670 Chipset
Memory	2x 8GB SO-DIMM DDR5-4800
Memory Slots	Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory	Models with Core™ i3/i5: Up to 64GB DDR5-4800 Models with Core™ i7: Up to 64GB DDR5-5200
Storage	512GB SSD M.2 2280 PCIe® 4.0×4 NVMe® Opal 2.0
Storage Support	Models with Intel® UHD graphics: Up to two drives, 2x M.2 SSD • M.2 SSD up to 2TB each
Card Reader	3-in-1 Card Reader
Optical	None
Audio Chip	High Definition (HD) Audio, Realtek® ALC233NL-VB2-CG codec
Speakers	3Wx2
Camera	5.0MP + IR Hybrid
Microphone	2x, Array
Power Supply	180W 90%
DESIGN
Display	23.8" FHD (1920×1080) IPS Anti-glare 250nits, 60Hz, 99% sRGB, hardware low blue light, flick free, eyesafe, non-touch
Touchscreen	None
Keyboard	USB Traditional Keyboard, Black, English
Mouse	USB Calliope Mouse, Black
Optional Bay	None
Expansion Slots	Models with Intel® UHD graphics: Three M.2 slots (one for WLAN, two for SSD)
Case Color	Black
Stand	UltraFlex V Stand
Mounting	VESA mount
Form Factor	AIO (23.8 inches)
Dimensions (WxDxH)	Lowest in flat mode: 539.6 x 344.19 x 227.54 mm (21.24 x 13.55 x 8.96 inches) Highest in vertical mode: 539.6 x 252.60 x 472.00 mm (21.24 x 9.94 x 18.58 inches)
Weight	Around 7.83 kg (17.3 lbs)
CONNECTIVITY
Ethernet	Integrated 100/1000M
WLAN + Bluetooth	Intel® Wi-Fi® 6 AX201, 802.11ax 2×2 + BT5.2
Rear Ports	1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 15W charging 3x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x HDMI® (HDMI in 1.4 / HDMI out 2.1 TMDS combo port) 1x DisplayPort™ 1.4 1x Ethernet (RJ-45)
Right Ports	3x USB-A (USB 10Gbps / USB 3.2 Gen 2) 1x headphone / microphone combo jack (3.5mm)
Optional Right Ports (configured)	1x card reader
Optional Ports (configured)	None
SECURITY & PRIVACY
Security Chip	Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
Fingerprint Reader	No fingerprint reader
Physical Locks	Kensington® Security Slot™, 3 x 7 mm
Chassis Intrusion Switch	Chassis Intrusion Switch
Additional Security	None
Other Security	ThinkShutter camera cover (camera models)
MANAGEABILITY
System Management	Non-vPro®
SERVICE
Base Warranty	3-year, Onsite
Included Upgrade	None
CERTIFICATIONS
Green Certifications	ENERGY STAR® 8.0 EPEAT™ Gold Registered ErP Lot 3 GREENGUARD® RoHS compliant TCO Certified 9.0 TCO edge
Other Certifications	TÜV Rheinland® Low Blue Light (Hardware Solution) Eyesafe® Certified 2.0 TÜV Rheinland® Flicker Free UL Anti-dust
Mil-Spec Test	MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Fungus, Solar Radiation, Contamination by Fluids, Salt Fog)
SOFTWARE
Operating System	Windows® 11 Pro, English
Bundled Software	None
ACCESSORIES
Bundled Accessories	None

Specifications

Manufacturer	Lenovo
CPU Generation	Intel 14th Generation
Screen Size	23.8"
Resolution	1920x1080
Refresh Rate	60Hz
RAM Size	16GB
Storage Size	512GB
Operating System	Windows 11 Pro
Panel	IPS
USB	USB 3.2 Type-A, USB 3.2 Type-C
CPU	Intel Core i5
Video Interface	DisplayPort, HDMI
WiFi Standard	Wi-Fi 6
CPU Speed	5.0Ghz
Integrated GPU	Intel UHD iGPU, Integrated Graphics
RAM Type	SODIMM DDR5
LAN Speed	1Gb
Bluetooth	Bluetooth
Storage Type	SSD
Warranty	3 Year Onsite
CPU Cores	14 Core
