GENERAL

Phase

Single Phase

Form Factor

Tower

UPS Topology

Line-interactive

Energy Saving Technology

GreenPower UPS™ Bypass Technology

Active PFC Compatibility

Yes

INPUT

Nominal Input Voltage ( Vac )

220

230

240

Input Voltage Range ( Vac )

169 ~ 271

Input Frequency ( Hz )

50 ± 3

60 ± 3

Input Frequency Detection

Auto-sensing

Rated Input Current ( A )

10

Input Connector Type

IEC C14

Detachable Power Cord Plug Type

AU x

Power Cord Length (ft.)

6

Power Cord Length (m.)

1.83

OUTPUT

Capacity (VA)

1350

Capacity (Watts)

810

On Battery Waveform

Pure Sine Wave

On Battery Voltage(s) ( Vac )

230 ± 5 % (Under a test load of<60%. When the load>60%, the output voltage range may>5%.)

On Battery Frequency ( Hz )

50 ± 1%

60 ± 1%

Automatic Voltage Regulation (AVR)

Single Boost

Overload Protection

Internal Current Limiting

Outlet(s) - Total

6

Outlet Type

AU x 6

Outlet(s) - Battery & Surge Protected

6

Typical Transfer Time ( ms )

8 (At normal sensitivity)

USB Charging Port(s)

USB-A x 1

USB-C x 1

USB Charging Total Output

5 V/ 4 A Max

USB-A Charging Output

5 V/ 2.4 A Max

USB-C Charging Output

5 V/ 2.4 A Max

BATTERY

Runtime at Half Load ( min )

9.6

Runtime at Full Load ( min )

2.1

Typical Recharge Time ( Hours )

8 (Recover to 90% after full load discharge)

User-replaceable

Yes

Battery Type

Sealed Lead-acid

Battery Cartridge (RBP)

RBP0146

Battery Cartridge (RBP) Quantity ( pcs )

1

SURGE PROTECTION & FILTERING

Surge Suppression ( Joules )

405

Network Protection RJ45

1-in, 1-out

MANAGEMENT & COMMUNICATIONS

LCD Panel

Yes

LCD Types

Color LCD

Tiltable LCD Panel

22°

LCD Information Display

Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Event & Log

LCD Setting & Control

Alarm Setting, Input & Output, Battery Setting, Event & Log

LED Indicators

Power On

HID Compliant USB Port(s)

1

Serial Port

Dry Contact

Audible Alarms

Battery Mode, Low Battery, Overload, UPS Fault

Management Cable ( pcs )

USB Cable x1

Ethernet Data Transmission Speed

Up to 1Gbps

Power Management Software

PowerPanel Business (Recommended)

SNMP/HTTP Remote Monitoring

Yes - with optional RMCARD205

PHYSICAL SIZE - UPS MODULE

Dimensions (WxHxD) (mm.)

100 x 281.5 x 354.1

Weight (lbs.)

22.05

Weight (kg.)

10

ENVIRONMENTAL

Operating Temperature (°F)

32 ~ 104

Operating Temperature (°C)

0 ~ 40

Operating Relative Humidity (Non-condensing) ( % )

0 ~ 95

Operating Elevation ( feet/meters )

0-9,843 feet (0-3,000 meters)

Storage Temperature (°F)

5 ~ 113

Storage Temperature (°C)

-15 ~ 45

Storage Relative Humidity (Non-condensing) ( % )

0 ~ 95

Storage Elevation ( feet/meters )

0-49,213 feet (0-15,000 meters)

Online Thermal Dissipation ( BTU/hr )

19

CERTIFICATIONS

Certifications

CE, RCM

RoHS

Yes
